- Page 1 _____________________________________ ..………………………………………………………… .. Sprint Maintenance Station Replacement Technical Support Version 2.0 Date 5/13/13...
- Page 2 AnaJet Inc. 3050 Redhill Ave Costa Mesa, CA 92626 Telephone: 714.668.6000 Toll Free: 877-6-ANAJET (877.626-2538) Fax: 714.662.3600 Revision History Revision Description Author Date Initial release. Craig Norton – Tech support 5/13/2013 Replacement – Sprint Maintenance Station Page 2 of 9...
- Page 3 Technical Support Title for the guide Introduction The technical Support team had determined that your Sprint’s Maintenance Station needs to be replaced. These step-by-step instructions are designed to assist our end users in the replacement procedures. Scope This applies to Sprint printers only.
- Page 4 7. Unscrew the two green ground leads from the front body panel screw. 8. Reassemble the new Control Panel by reversing the above steps. 9. Adjust the backlight and character contrast if required, see 4.7. Replacement – Sprint Maintenance Station Page 4 of 9...
- Page 5 (See Photos 2.0 and 2.1) 3. Remove the Bezel (Photo 2.2) 4. Remove the fixed end of the Tube Carrier from the Tube Carrier and Tube Bracket (Photos 2.3 and 2.4) Replacement – Sprint Maintenance Station Page 5 of 9...
- Page 6 Print Head to minimize leakage from the Dampers. 6. Unplug the cables to J1 and J2 from the Ink LED PCBA and the connector labeled PIN 1. (Photos 2.5 and 2.6) Replacement – Sprint Maintenance Station Page 6 of 9...
- Page 7 Step 3 – Removing Maintenance Station 1. Remove the Waste Ink Tank 2. Release the Print head carriage and move it to the left, away from the Maintenance Station. (See your operator’s manual) Replacement – Sprint Maintenance Station Page 7 of 9...
- Page 8 This will allow you to pivot the circuit board to access and remove the screw behind A2, and also remove screw holding ground wire with the short shaft Phillips head screwdriver. (Photo 3.4) Replacement – Sprint Maintenance Station Page 8 of 9...
- Page 9 7. The last step is to simply remove the Maintenance Station. Rotate the Maintenance Station front end down, and then slide it out from underneath. 8. Install the new Maintenance Station by reversing the above steps. Replacement – Sprint Maintenance Station Page 9 of 9...
