4. Put the back and the left side (part II) on the lower sides and
screw them together from the side. (screws 5x80) Take care that
no screws can be seen on the inside. Use the same procedure
for the right and the front side.(fig.1.7)
Now your sauna should look as shown here. (fig.1.6)
5. Now put the upper log board onto the front wall and screw
it to the sides. (fig.1.8)
6. Then fix the roof supporting battens to the sides at a distance
of 9.5 cm from the upper edge of the side to the lower batten
edge. (screws 4x70 - fig.1.9) The rounded batten edges should
be visible below.
