Assembly instructions
EN
fig. 1.1
fig. 1.2
fig. 1.4
fig. 1.5
04
1. First place the right side and the back wall (part I lower
straight) next to each other, so that the screws can be seen on
the outside, as shown in fig.1.1. Screw the side to the back
wall. (screws 5x80)
Use the same procedure for the left side. The back wall is fixed
between both outer sides.
2. Now take the front log board with the opening for the door
and put the narrow right wall element onto it. (The element has
got a projecting batten on the right side at the bottom. fig.1.2)
Now screw the lower log board from the front to the batten
(screws 3x40 - fig.1.3) and on the side to the outside.
fig. 1.3
Use the same procedure for the left wall element. Now the sauna
cabin should look as in fig.1.4.
3. Check if the sauna cabin is at right angles by measuring
diagonally the length of both sides. (fig.1.5) The measurements
of both sides should be the same. ( +/- 2mm;)
Then check the sides with the spirit level if they are horizontal by
putting the spirit level on the upper edge of the side.
