IMPORTANT
Before Commencing Assembly:
• Read all instructions COMPLETELY
• Ensure all listed parts are present
If any parts are missing from Parts List 1, please
contact 1800 822 823.
If any parts are missing from Parts List 2, please
Contact HAFELE, Australia at 1300 559 387.
.
• Ensure you have the required tools to
complete the assembly
(Philips Head Screwdriver, Hammer &
Wood Glue)
CAUTION
• Ensure your work surface is solid, level,
clean and flat (DO NOT WORK ON
CARPET)
• Ensure ALL melamine edges are facing
as described in the Assembly Instructions.
IF YOU NEED TO CONTACT US WITH
REGARD TO THIS PRODUCT PLEASE CALL
1800 822 823 AND QUOTE THE BATCH
NUMBER SHOWN ON THE CARTON.
WARNING: Contains small parts, keep out
of reach of children.
615 Goodwood Road, Panorama SA 5041
PO Box 18 Melrose Park SA 5039
Telephone: 1800 822 823, Fax: (08) 8460 0009
Email: furniture@bedfordgroup.com.au
www.bedfordgroup.com.au
Global
2 Door Tall/Split Unit
Page 1 of 10
ASSEMBLY GUIDE
Advertisement
Related Manuals for Bedford 2 Door Tall/Split Unit
Summary of Contents for Bedford 2 Door Tall/Split Unit
- Page 1 ASSEMBLY GUIDE 2 Door Tall/Split Unit IMPORTANT Before Commencing Assembly: • Read all instructions COMPLETELY • Ensure all listed parts are present If any parts are missing from Parts List 1, please contact 1800 822 823. If any parts are missing from Parts List 2, please Contact HAFELE, Australia at 1300 559 387.
- Page 2 Parts List 1 2 Door Tall/Split Unit Part No. Description Qty. Part No. Description Qty. Part No. Description Qty. Fix Shelf Top & Bottom Adjustable Shelf 1672 Part No. Description Qty. Part No. Description Qty. Part No. Description Qty. Toe Rail...
- Page 3 Parts List 2 2 Door Tall/Split Unit Part No. Description Qty. Part No. Description Qty. Part No. Description Qty. Hinge Glides Shelf Support Part No. Description Qty. Part No. Description Qty. Screw Cams Hardware Pin Description Qty. Part No. Description Qty.
- Page 4 Step 1 8 (Left Cabinet End) Cabinet end panel Please lay cabinet end panel (8) on flat protected surface with holes facing up. Please note that left and right end panels look similar as they are reversible. Screw the hardware pins (17) in the holes shown.
- Page 5 Step 4 Fix shelf, top and bottom Lay the top (1), bottom (1) and fix shelf (2) on a flat surface with holes facing up and insert the cams (16) in holes with arrows pointing to the side as shown. Make sure to push the cams (16) all the way in by gently tapping them with hammer.
- Page 6 Step 6 Assembling the division Please lay down the division panel (9) on a flat protected surface and insert 9 (Division) the cams (16) in the holes as shown. Make sure to push cams (16) all the way in by gently tapping them with hammer. Screw in the hardware pins (17) in the holes shown.
- Page 7 Step 9 Assembling right end panel Edge Strip It is recommended to insert small amount of glue in the dowel holes 8 (Cabinet End Panel) in the rails (4b) & (6) and clean the excess glue with a damp cloth. Making sure, that, all the hardware pins and dowel holes in the left cabinet end align with the above...
- Page 8 Step 11 Attaching plastic glides While unit is lying face down, attach the four plastic glides (14) on the underside corners of the cabinet end panels. Step 12 Inserting adjustable shelves and assembling doors to the unit Caution: If the unit is not secured to the wall, it may tip forward, when, the cabinet is opened empty.
- Page 9 Step 13 Hinge adjustment Caution: If the unit is not secured to the wall, it may tip forward, when, the cabinet is opened empty. • Screw 1 is used for gap adjustment between cabinet end and door. • Screw 2 is used to secure hinge to end. •...
