- Page 1 Electric Bike L2 User's Manual & folding instructions SHENZHEN QLHX TECHNOLOGY CO., LTD. No. 60, Dawei area 1, Longxin Community, Baolong street, Longgang District, Shenzhen Made in China...
- Page 2 FIIDO Electric Bicycle Catalog Ⅰ．Important Note Ⅱ．Product components Ⅲ．Unfolding instructions Ⅳ．Folding instructions Ⅴ．Product parameters...
- Page 3 Ⅰ．Important Note a) This manual include important safety performance information and service information. Please make sure you have read the following warning content before the first time you use our product. b) If you borrow your electric bicycle to other people, please let the user read this manual, it could help to decrease the risk of accident.
- Page 4 Ⅱ．Product components 1、 Saddle 2、 Seat tube 3、 Battery box 4、 Charge port 5、 Saddle 6、 taillight 7、 Controller box 8、 Rear Suspension 9、 Reflector 10、 Brake disc 11、 Motor 12、 Chain extender 13、 Quick lock 14、 Folding system 15、 Chain 16、 Chain wheel 17、 Crank 18、 Pedal 19、 Handle bar 20、 Quick lock 21、...
- Page 5 1.Brake power off system 2.Light button 3.horn button 4.Mobile phone bracket &USB Port 5.Quick lock 6.Assistance Gears light 7.Power light 8.Assistance Gears 9.Power on/off button(Long press on or off) 10.Assistance Gears 11.Speed handlebar (Note:After the car is stationary, it does not run for 10 minutes to enter the sleep mode and automatically shut down) Battery charging port (The charging port is located on the left side of the controller box.) Use a 15mm open spanner to clamp the pedal shaft core...
- Page 6 Ⅲ．Unfolding instructions 1.Unfold the frame,lock the frame folding handle,and lock the frame folder safety clasp. 2.Fold the riser to the upper end,lock the riser folding handle,adjust the riser safety hook to the tightening state,and adjust the position of the T handle. 3.Open the clip on the seat tube clamp and insert the seat tube into the position within the marking line on the seat tube.
- Page 7 Ⅳ．Folding instructions Step 1. Open the quick lock on the head end, to let the handle be perpendicular to the care frame. Step 2. Open the quick lock on the Stem, lower the riser,as well as locking the quick lock. Step 3.
- Page 8 Ⅴ．Product parameters Name Specification Electric Bike System FIIDO System Electric Motorcycle Support Power Assist System Support Power Assist System 3 Gears Assist Max Load weight 120kg Maximum Speed 25km/h Maximum Range Up to 60km Battery High quality lion battery 48V 12.5Ah/20Ah/25Ah...
