- Page 1 QUICK START GUIDE LCX21 Lyra RGBW 1 x 2 Soft Panel Digital Color Light What’s Included 1 x LCX21 Light Fixture 1 x Power supply 1 x Power cord 1 x Yoke 1 x Safety Cable because we’re filmmakers too www.ikancorp.com | 713.272.8822 | sales@ikancorp.com...
-
Page 2: General Information
General Information Thank you for buying the Lyra 1 x 2 RGBW Studio Light Soft Panel with DMX Control. This fixture has been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this unit. -
Page 3: Fixture Overview
Fixture Overview Front View A. Yoke Locking Screw B. Accessory Clip C. Front Diffuser Panel D. Mount Locking Screw E. Yoke Back View A. V-lock Release Button B. V-lock Battery Plate C. AC Power Adapter D. Cooling Fan Air Outlet E. -
Page 4: Control Panel
Control Panel Battery PRESS DATA DMX OUT BACK DMX IN INPUT: DC30V RGBW MENU MAX POWER: 300W Made in China GELS A. DMX Input E. Knob 1: TURN to NAVIGATE G. Knob 3: TURN to NAVIGATE B. DMX Output PRESS to SELECT H. -
Page 5: Lcd Screen / Menu
LCD Screen / Menu Menu Operation 1. TURN knob 1 to choose the desired sub- menu and PRESS to SELECT. 2. The shortcut buttons below the LCD screen can also be used to enter a sub-menu directly. 3. To navigate back to the Main Menu, PRESS knob 2 to go BACK or push the shortcut MENU button below the LCD screen. - Page 6 Sub-Menu Functions Special FX (Effects Presets) To SCROLL through FX, TURN knob 1 To SELECT desired FX, PRESS knob 1 FX: PARTY FX: COP SATURATION: 0 - 100% To adjust, TURN knob 1 INTENSITY: 0 - 100% To adjust, TURN knob 2 INTENSITY: 0 - 100% To adjust, TURN knob 2...
- Page 7 Sub-Menu Functions GEL (Gel Filters) To SCROLL through Gels, TURN knob 1 To SELECT desired Gel, PRESS knob 1 TEMPERATURE: 3200 K / 5600 K To toggle, TURN knob 1 INTENSITY: 0 - 100% To adjust, TURN knob 2 APPLY GEL: YES / NO To toggle, TURN knob 3 LCX21 #...
- Page 8 Sub-Menu Functions FAN (Cooling Fan Speed Options) To SCROLL through Fan options, TURN knob 1 To SELECT desired Fan option, PRESS knob 1 * Auto Speed - The fan runs according to the temperature inside the light * Speed Options: OFF, LOW, MEDIUM, HIGH LANGUAGE (Display Language Options) To SCROLL through Language options, TURN knob 1 To SELECT desired Language, PRESS knob 1...
- Page 9 Indicator Function Description Battery Indicator Battery When the Battery indicator light is ON, the V-lock battery is being used to power the light. When the Battery indicator light FLASHES, the V-lock battery is running low. DATA When the Battery indicator is OFF, the AC power adapter is being used to power the light. Note: When the light is battery powered, the light fixture’s max output power is reduced to 80%.
-
Page 10: Optional Accessories
Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture. Please refer all other service issues to an authorized Ikan service technician. Should you need any spare parts, please order genuine parts from your local Ikan dealer. -
Page 11: Learn More
Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2019 Ikan International. All rights reserved. -11 - because we’re filmmakers too...
