- Page 1 QUICKSTART GUIDE Lyra Daylight LED Half x 1 Soft Light Lyra Bi-Color LED Half x 1 Soft Light LW10 Lyra Daylight LED 1x1 Soft Light LB10 Lyra Bi-Color LED 1 x 1 Soft Light © 2016 ikan Corporation. All rights Reserved...
- Page 2 Power the LEDs: The Lyra light comes with an included AC power supply and 6 foot cable. This allows the user to plug into any standard 120-240VAC electrical outlet. The Lyra LED Soft light can be powered from either an AB Mount pro battery, or a V-Mount battery.
- Page 3 Press and Hold “C” & “D” for 5 seconds to enable/disable sound • Button “C” and “D” adjusts the color temperature Optional Accessories Some other products that work well with the LYRA Soft Lights available from Ikan include: Heavy Duty Light Stand HD-STND 2 Stage Roller Stand 10 ft 6 in...
- Page 4 Lyra Daylight LED Half x 1 Soft Light Specifications Specs Head Type Daylight 5600K Rating 51w ; 14-18VDC Light Source 255 0.2 watt LEDs Power Supply Input: 110-220VAC ; Output:15VDC Lens ½ Stop, Soft Diffusion Beam Angle 110° Yoke & Pin 30°...
- Page 5 Lyra Bi-Color LED Half x 1 Soft Light Specifications Specs Head Type Bi-Color 5600K-3200K Rating 51w ; 14-18VDC Light Source 510 0.2 watt LEDs Power Supply Input: 110-220VAC ; Output:15VDC Lens ½ Stop, Soft Diffusion Beam Angle 110° Yoke & Pin 30°...
- Page 6 LW10 Lyra Daylight LED 1x1 Soft Light Specifications Specs Head Type Daylight 5600K Rating 90w ; 14-18VDC Light Source 450 0.2 watt LEDs Power Supply Input: 110-220VAC ; Output:15VDC Lens ½ Stop, Soft Diffusion Beam Angle 110° Yoke & Pin 30°...
- Page 7 LB10 Lyra Bi-Color LED 1 x 1 Soft Light Specifications Specs Head Type Bi-Color 5600K-3200K Rating 90w ; 14-18VDC Light Source 900 0.2 watt LEDs Power Supply Input: 110-220VAC ; Output:15VDC Lens ½ Stop, Soft Diffusion Beam Angle 110° Yoke & Pin 30°...
- Page 8 (*Even if the product is still within the warranty period.) • Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2016 ikan Coporation. All rights reserved...
