LSKT-002
ON THE GO-02 3PT Tungsten Fresnel Light Kit (Lightstar)
What's Included
1 x 150W Tungsten Fresnel
1 x 300W Tungsten Fresnel
1 x 650W Open Face Light
1 x Scrim Set for 150W
1 x Scrim Set for 300W
1 x Gel Frame 150W
1 x Gel Frame 300W
1 x Set of 3 Light Stands
1 x Carrying Case w/ Wheels
1 x FDV Lamp (150W)
1 x FKW Lamp (300W)
1 x FAD Lamp (650W)
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
CHECKED BY
because we're filmmakers too
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ikan Lightstar LSKT-002
Summary of Contents for Ikan Lightstar LSKT-002
- Page 1 Quick Start Guide LSKT-002 ON THE GO-02 3PT Tungsten Fresnel Light Kit (Lightstar) What’s Included 1 x 150W Tungsten Fresnel 1 x 300W Tungsten Fresnel 1 x 650W Open Face Light 1 x Scrim Set for 150W 1 x Scrim Set for 300W 1 x Gel Frame 150W 1 x Gel Frame 300W 1 x Set of 3 Light Stands...
- Page 2 Ikan is the exclusive distributor of Lightstar products in the United States. Getting to know your LIGHTSTAR Light The Lightstar LSW-010 (150 Watt) LSW-001 (300 Watt) LHS-001 (650 Watt) fixtures are intended for professional applications, and are only to be operated by qualified persons.
- Page 3 Inserting Accessories Inserting and exchanging accessories must be carried out from a stable position. On the LSW-010, lift the top latch and turn it by 90° to the left. On the LSW-001 press the pin on the side of the holding bracket to release the spring. Insert accessories e.g. barn door, or scrim into the bracket. Lift the top latch and turn it back into original position.
- Page 4 LSW-010 Specs Head Type 3200K Rating AC Volts 120 v ac, 50-60Hrz Light Source 1-150 Watt Bulb Power Supply 6 ft Power Cable Dimming Control Focusing Knob Lens 1.9 In. Fresnel Lens Focusing Rotating Rear Knob Beam Angle 11-55º Cooling System Air Cooled Yoke Cast Aluminum w/ 1...
- Page 5 LSW-001 Specs Head Type 3200K Rating AC Volts 120V AC, 50-60Hrz Light Source 1-300 Watt Bulb Power Supply 6 ft Power Cable Dimming Control Focusing Knob Lens 3.1 In. Fresnel Lens Focusing Rotating Rear Knob Beam Angle 14-53º Cooling System Air Cooled Yoke Cast Aluminum w/ 1...
- Page 6 LHS-001 Specs Head Type 3200K Rating 120V AC, 50-60 Hz Light Source 1-650 Watt Bulb Power Supply 6' Power Cable Control Focusing Knob Lens No Lens 36° - 70° Beam Angle Cooling System Air Cooled Yoke Cast-Aluminum 1 1/8" Pin Fixture Size 8 x 10 x 7 In.
- Page 7 Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2017 ikan Corporation. All rights reserved because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
