INSTALLATION INSTRUCTIONS
DXV Belshire
Console Lavatory Kit
Models: D19080000.550 — Marble Top Console - No Hole
D19080003.550 — Marble Top Console - Three Hole
D21065000.144 — Console Frame - Platinum Nickel
D21065000.427 — Console Frame - Satin Brass
D20205000.415 — Undercounter Lavatory
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully
before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
For rough-in dimensions and supply line information, see spec page or web site
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
Basin Wrench
Hacksaw
Pipe Wrench
EXPLODED VIEW
ITEM # DESCRIPTION
1 Left Console Frame
2 Right Console Frame
3 (2) Horizontal Support Tubes
4 Marble Top
5 Left Side Marble Panel
6 Right Side Marble Panel
7 Glass Shelf
NOTE: Repair Part 770268-200.0070A Set
Screws & Allen Key
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2020
™
Regular Screwdriver
Phillips Screwdriver Drill
Adjustable Wrench Channel Lock
1
Silicone Tape Measure
Level
Putty Knife
4
5
7
3
- 1 -
Screws & Washers
10'
8-#10 x 1"
Machine Screws
Saber Saw
8-#10 x 2"
Wood Screws
Tubing Cutter
770283-100 (2/2020)
Supplied
6
2
