DXV Oak Hill Vanity D19010030.620 Installation Instructions

INSTALLATION INSTRUCTIONS

Oak Hill
™
Vanity
Models: D19010030.620
D19010030.239
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin.
(Certain installations may require professional help.) Also be sure your installation conforms
to local codes.
To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading. Also avoid extreme
changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units. Avoid placing
furniture directly under windows.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
Regular Screwdriver
Phillips Screwdriver
Square
ROUGHING-IN DIMENSIONS:
• For reference
30-1/2"
(775 mm)
8"
(203 mm)
38-13/16"
(986 mm)
FINISHED
FLOOR
30"
(762 mm)
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
Hacksaw
Adjustable Wrench
Plumbers' Putty or
Caulking
Basin Wrench
ø1"
(ø30 mm)
22-1/4"
(566 mm)
41-1/8"
(1044 mm)
IMPORTANT:
THE OAK HILL LAVATORY
(MODEL D20175) CANNOT BE
INSTALLED AS A WALL HUNG
LAVATORY. THE LAVATORY MUST
BE INSTALLED USING THE
OAK HILL CONSOLE STAND
OR VANITY.
Pipe Wrench Channel Locks
Level
Putty Knife
30-1/2"
(775 mm)
28-1/2"
(724 mm)
20-1/4"
(515 mm)
- 1 -
Tubing Cutter Tape Measure
Electric
Drill
22-1/16"
(560 mm)
4"
(102 mm)
23"
(585 mm)
36-1/16"
(916 mm)
FINISHED
FLOOR
22-1/16"
(560 mm)
770233-100 Rev. B (6/17)
10'
Saber Saw
6-1/2"
(165 mm)
