DXV Modulus D19050036 Series Installation Instructions

INSTALLATION INSTRUCTIONS

DXV Modulus
Single Mirror/Double Mirror
36" Single — Model D19050036 Series
49" Double — Model D19055049 Series
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin.
(Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
Square
ROUGHING-IN DIMENSIONS:
• For reference
D19050036
20-1/16"
(510 mm)
D19055049
20-1/16"
(510 mm)
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
™
Level
36"
(914 mm)
49-3/16"
(1250 mm)
10'
Electric
Drill Tape Measure
- 1 -
Hammer
#8 Screws &
Phillips Screwdriver
Wall Anchors
1-9/16"
(40 mm)
18-1/8"
(460 mm)
1-9/16"
(40 mm)
18-1/8"
(460 mm)
7302329-100 Rev. A (10/17)
