Parts And Features - Whirlpool RCS2002 Use & Care Manual

This manual covers different models. The cooktop you have purchased may have some or all of the items listed. The locations and
appearances of the features shown here may not match your model.
Control Panel
1. Surface Cooking Area Locator
2. Power On Indicator Light
Cooktop
1. Model and Serial Number Plate
(located on outside bottom of
cooktop)

PARTS AND FEATURES

1
2
3. Left Rear Control Knob
4. Right Rear Control Knob
1
2. Plug-in coil element with one-piece
reflector bowl
3
4
5
6
5. Left Front Control Knob
6. Right Front Control Knob
2 3
3. Control panel
5
