PARTS AND FEATURES

This manual covers different models. The cooktop you have
purchased may have some or all of the items listed. The locations
and appearances of the features shown here may not match
those of your model.
Control Panel
A
A. Surface burner locator
B. Left rear control knob
C. Right rear control knob
Cooktop
A B
A. Model and serial number plate
(located under cooktop)
B. Surface burner grate
4
B
C
D
E
D. Left front control knob
E. Right front control knob
C
D
C. Surface burner cap
D. Control panel

COOKTOP USE

Cooktop Controls

WARNING
Fire Hazard
Do not let the burner flame extend beyond the edge of
the pan.
Turn off all controls when not cooking.
Failure to follow these instructions can result in death
or fire.
Electric igniters automatically light the surface burners when
control knobs are turned to LITE.
Before setting a control knob, place filled cookware on the grate.
Do not operate a burner using empty cookware or without
cookware on the grate.
To Set:
1. Push in and turn knob counterclockwise to LITE.
All four surface burners will click. Only the burner with the
control knob turned to LITE will produce a flame.
2. Turn knob anywhere between HI and LO. Use the following
chart as a guide when setting heat levels.
SETTING RECOMMENDED USE
LITE
HI
MED HI
Medium High
MED
Medium
MED LO
Medium Low
LO
REMEMBER: When cooktop is in use, the entire cooktop
area may become hot.
Light the burner.
Start food cooking.
Bring liquid to a boil.
Hold a rapid boil.
Quickly brown or sear food.
To fry chicken.
Maintain a slow boil.
Fry or sauté foods.
Cook soups, sauces and gravies.
Stew or steam food.
Simmer.
Keep food warm.
Melt chocolate or butter.
