Parts And Features - Whirlpool GLT3657 Use And Care Manual

These instructions cover several different models, and not all models are shown. The cooktop you have purchased may have some or
all of the items listed. The locations and appearances of the features shown here may not match those of your model. All BTU/h ratings
shown are for Natural gas unless otherwise noted.
Model SCS3617 (36" [91.4 cm] shown)
Model SCS3017 and W3CG3014 (30" [76.2 cm] not shown)
Control Panel
A
B
C
D
F
Cooktop
A. 12,500 BTU/h burner
(10,500 BTU/h on W3CG
model)
B. Surface burner cap
C. Left surface burner grate

PARTS AND FEATURES

E
E
D
C
B
A
D. 9,100 BTU/h burner
E. Model and serial number plate
(under cooktop)
F. 12,500 BTU/h burner
(9,100 BTU/h on W3CG model)
A. Control knob off position
B. Left rear burner control knob
C. Right rear burner control knob
D. Left front burner control knob
E. Surface burner locator
F. Right front burner control knob
F
I
H
G. Right surface burner grate
H. Control panel
I. 5,000 BTU/h burner
G
