Inclinometer
with two programmable switchpoints
B1N360V-Q20L60-2UP6X3-H1151/3GD
Type code
Ident-No.
Measuring range
Mounting condition
Repeatability
Absolute accuracy (at 25 °C)
Temperature coefficient typical
Resolution
Hysteresis
Ambient temperature
Operating voltage
Residual ripple
No-load current I
0
Residual current
Rated insulation voltage
Output current
Response delay
Dropout delay
Short-circuit protection
Voltage drop at I
e
Wire breakage / Reverse polarity protection
surge protection
Output function
Approval acc. to
Device designation
Design
Dimensions
Housing material
Connection
Vibration resistance
Shock resistance
Protection class
MTTF
Power-on indication
Switching state
Included in scope of supply
1 / 5
TURCK Inc. ñ 3000 Campus Drive Minneapolis, MN 55441-2656 ñ Phone: 763-553-7300 ñ Application Support: 1-800-544-7769 ñ Fax 763-553-0708 ñ www.turck.com
B1N360V-Q20L60-2UP6X3-H1151/3GD
1534112
0...360°
vertical
ð 0.2 % of full scale
+/- 0.5 °
0.03 °/K
ð 0.14 °
0...1 %
-30...+70 °C
in the explosion hazardous area see instruction
leaflet
10...30VDC
ð 10 % U
ss
ð 35 mA
ð 0.1 mA
ð 0.5 kV
ð 500 mA
500 ms
350 ms
yes/ thermal
ð 1 V
yes/ complete
-30...40VDC [U
]
b max.
4-wire, NO/NC , 2 x PNP
ATEX declaration of conformity TURCK Ex-12003H
X
Ex II 3 G Ex nA IIC T5 Gc/II 3 D Ex tc IIIC T85°C Dc
rectangular, Q20L60
60x 30x 20 mm
plastic, PC
male, M12 x 1
55 Hz (1 mm)
30 g (11 ms)
IP68 / IP69K
203 years acc. to SN 29500 (Ed. 99) 40 °C
LED green
LED yellow
Security clip SC-M12/3GD
ATEX category II 3 G, Ex Zone 2
ATEX category II 3 D, Ex Zone 22
Rectangular, height 20 mm
Plastic, PBT-GF20-V0
Indication of operating voltage and
switching state
Two programmable switching outputs
Switchpoints selectable in a range be-
tween 0° and 360°
Adjustable travel path and hysteresis
4-wire DC, 10...30 VDC
Male M12 x 1
Wiring diagram
Functional principle
Inclination is determined by a wear-free semi-
conducting sensor element.
