ProASIC3/E Proto Kit
Quickstart Card
Kit Contents – A3PE-PROTO-KIT, A3PE-BRD1500-SKT
Quantity
1
ProASIC
1
FlashPro3 programmer (not included with A3PE-BRD1500-SKT)
1
9 V power supply with international adapters
CAT5E RJ45
Connectors
for LVDS
Communications
Removable
Shunts to
Isolate All I/Os
for Prototyping
Oscillator for
System
Clock
Manual
Clock Option
SMA for
Optional
External
Oscillator
© 2012 Microsemi Corporation. All rights reserved.
®
3 Starter kit board with an A3PE1500-PQ208
LCD Display
Module
8 LEDs
Description
Wall Mount
Power
4 Switches
Interboard ISP
Connector
Removable
Shunts to
Isolate All I/Os
for Prototyping
FlashPro3
ISP Connector
ProASIC3/E in
PQ208 Package
Every PQ208
Pin Accessible
for Prototyping
Removable Shunts to Isolate
All I/Os for Prototyping
