Revision 1.1 PRODUCTION DATA – Information contained in this document is proprietary to Microsemi and is current as of publication date. This document may not be modified in any way without the express written consent of Microsemi. Product processing does not necessarily include testing of all parameters. Microsemi reserves the right to change the configuration and performance of the product and to discontinue product at any time.
PD-IM-7504B Marketing Board - User Guide 1 About this Guide This user guide provides both a description and operation procedures for Microsemi's PD-IM-7504B Marketing Board, which is used to evaluate the performance of PD69104A/B/B1 PoE applications. Audience This user guide is intended for qualified personnel, meaning operators and technicians who have a background in electronics and are familiar with its basic concepts.
PD-IM-7504B Marketing Board - User Guide 2 Introduction Microsemi’s PD-IM-7504B Marketing Board (see Figure 1) provides designers with the needed environment to evaluate the performance and implementation of PoE and PoE extended mode applications, based on PD69104A/B/B1 PoE Manager. Marketing board enables PoE designers to evaluate Microsemi's PoE solution with...
PD-IM-7504B Marketing Board - User Guide Marketing Board Interfaces and Connections Board has several interfaces: RJ45 interface: Running from PD69104A/B/B1 to 4 PDs (powered devices) connectors: DC in (V ) connection (J1) main LEDs indication: V power OK, Power limit LEDs main ...
Package Contents Upon opening the Marketing Board package, verify all parts itemized in the packing list are included. If any part is missing or seems damaged; contact local representative or Microsemi's Headquarters. Package contents for standard shipments are as follows: ...
PD-IM-7504B Marketing Board - User Guide DC jack connectors (J1) See Figure 2. DC in (V ) connection, used to power Marketing Board, 44V > V > 57V main main Table 2: V Connectors Pin No. Signal Name Description Positive main voltage (referenced to AGND)
PD-IM-7504B Marketing Board - User Guide LEDs Indication D1 – V indication . MAIN D3 – MAX power indication. (Indicates power budget is reaching its limit) Port Status LED– in front of each port in the RJ45 connector there is a green LED that indicates whether port is operating.
PD-IM-7504B Marketing Board - User Guide 5 Installation This chapter describes the steps required for installing and operating the Marketing Board with any PoE application. Preliminary Considerations and Safety Precautions Prior to powering the board, connect all required peripherals.
PD-IM-7504B Marketing Board - User Guide 6 Relevant Documents PD69104A datasheet, catalogue number DS_PD69104A PD69104B datasheet, catalogue number DS_PD69104B PD69104B1 datasheet, catalogue number DS_PD69104B1 Serial Communication Protocol user guide PD63000_UG PD69104A reg. map user guide, catalogue number 06-0480-056 ...
Page 12
Microsemi. If the recipient of this document has entered into a disclosure agreement with Microsemi, then the terms of such Agreement will also apply. This document and the information contained herein may not be modified, by any person other than authorized personnel of Microsemi.
