Aux Mode - Electro-Harmonix Pitch Fork+ Manual

M B
ODE UTTON
Each Mode button allows for control over its corresponding parameters.
When a Mode button is pressed, it will illuminate, and display its current
selection. You can then use the VALUE knob to scroll values, enter a sub-
menu, or save and load presets.
AUX Mode – In AUX mode, the VALUE knob is used to select the channels
that are sent to the AUX output. The selected channels will not be sent to
the MAIN output with the exception of "ALL."
IN
– sends the unaffected input signal directly to the AUX output
▪
DRY
– DRY knob channel sent to the AUX output
▪
D+S2
▪
SHF2
– SHIFT 2 channel is sent to AUX output
▪
ALL
– DRY, SHIFT 1 and SHIFT 2 channels are sent to both the
▪
AUX and MAIN outputs
BYPS.
▪
menu
BYPS
The sub-menu in the AUX mode selects if and how the BYPASS
footswitch affects the AUX output.
BYP.
– Selects if the BYPASS Footswitch applies to AUX
▪
•
•
TYPE.
▪
•
•
F
UNCTIONS
– Both DRY and SHIFT 2 channels are sent to AUX output
– Press VALUE encoder to enter bypass footswitch sub-
ON
– AUX output is toggled between the AUX mode
selection and bypass TYPE via the BYPASS Footswitch.
OFF
– BYPASS FSW has no effect on AUX output. AUX
output remains active unless controlled by USER
footswitch.
– Bypass type for AUX Output when BYP is set to ON
NORM
– Sends the unaffected INPUT signal directly to
AUX output when AUX is bypassed
MUTE
– Mutes AUX Output when AUX is bypassed
6
