With the USER mode button is set to JUMP, any number of presets can
be chained together. To set up a JUMP preset chain:
1. Press the PRESET button and use the VALUE knob to select the
preset that will start the preset chain.
2. Press the USER mode button and use VALUE to select JUMP.
3. Press VALUE to enter the JUMP sub-menu.
4. Turn VALUE to select the preset that the USER footswitch will
jump to and load.
5. Press PRESET, then press and hold VALUE for 2 seconds to save
the preset.
selection to revert to its previous value when the preset was
loaded. You must save before pressing the USER footswitch in
the following step.
6. Press the USER footswitch to jump to the next preset in the chain
7. Repeat Steps 2-6 to add more presets to the chain.
8. To close a jump preset chain loop, set the JUMP value for the
preset at the end of the chain to JUMP back to first preset in the
chain set in Step 1.
loop the chain.
X-MOD Mode – Press VALUE to enter cross modulation (X-MOD) and
SHIFT2+DETUNE2 (S2D2) sub-menus. Cross Modulation can be used to
create ring mod and frequency modulation effects. S2D2 adds SHIFT 2's
detune value to its current SHIFT interval.
1->2.
▪
1 will modulate SHIFT 2.
• The total range is 0-100 and can lead to subtle and/or
1<-2.
▪
2 will modulate SHIFT 1.
• The total range is 0-100 same as
S2D2.
▪
2's detune setting to all SHIFT 2 semitone and octave intervals.
For example, if SHIFT 2 is set to 1OCT and SHIFT 2's detune menu
is set to +16c, when S2D2 is ON, SHIFT 2 transposes by a total
amount of 1OCT+16c. This is useful for creating lush detuning
sounds between SHIFT channels 1 and 2 when they are set to the
same SHIFT mode value. To adjust the amount of detune applied,
follow instructions for setting detune (
Important:
NOTE: Skip this step if you do not wish to
– Press, then turn VALUE to adjust the amount that SHIFT
intense modulation timbres. When set to 0, modulation is
disabled.
– Press, then turn VALUE to adjust the amount that SHIFT
– Press, then turn VALUE to toggle ON/OFF adding SHIFT
Skipping this step will cause the JUMP
D.
) on page 7.
10
1->2
, and 0 is OFF.
