DRAWER ON RIGHT
IMPORTANT: BEFORE STARTING TO ASSEMBLE THE BED - P LEASE READ THESE INSTRUCTIONS CAREFULLY
Parts Identification
1
4b
3
Parts Checklist
Ref.
Description
Headboard
1
Footboard
2
3
Side Panel (Drawer - can fit to left or right side)
4a&4b
Adjustable Support Legs
5
Side Pane l (Solid)
6
Wooden Slat Set
7
*Upgraded Sprung Slat Frame*
8
*Sprung Slat Frame Centre Support Leg*
160405
DRAWER ON LEFT
6
5
4a
2
Page 1 of 8
LUCIA STORAGE BED
SINGLE SIZE
PLEAS
E READ this sheet prior to assembly to familiarise
yourself with the various stages of construction. Carefully
open the pack supplied and check the contents against the
parts and fittings check list.
Do not destroy any of the packaging until you are certain
that you have all the necessary parts for the assembly.
Please ensure that the packaging is disposed of in
a safe environmentally friendly way.
CAUTION: There are small components used in the
construction of this unit. These loose items should be
kept away from young children during assembly, to avoid
the danger of choking.
Please read note below.
This leg (8) should not be fitted to
the slat frame - it is NOT needed.
8
7
Note - Either a Std wooden Slat Set (6), or if chosen at time of
purchase, an upgraded Sprung Slat Frame (7) & Leg (8), shall
be supplied in a separate box.
Qty
Ref. Description
1
9
Drawer Back Panel
1
10
Drawer Face Panel
1
11
Drawer Side Panels
1 Pr
12
Drawer Front Panel
1
14
Drawer Bottom Panel
1
15
Drawer Bottom Support Rails
16
Drawer Bottom Support Rail
1
Only supplied if upgraded sprung slat frame is chosen.
*
Note that in this application, Leg (8) is not required - do not
1
fit to slat frame or drawer cannot slide into position.
Drawer parts
9
11
14
15
16
15
12
10
11
Qty
1
1
2
1
1
2
1
Advertisement
Related Manuals for DREAMS LUCIA
Summary of Contents for DREAMS LUCIA
- Page 1 LUCIA STORAGE BED SINGLE SIZE PLEAS E READ this sheet prior to assembly to familiarise yourself with the various stages of construction. Carefully DRAWER ON RIGHT open the pack supplied and check the contents against the parts and fittings check list.
- Page 2 Spring Washers (for M6 bolt) Flat Washers (for M6 bolt) EXTRA HARDWARE SUPPLIED WITH THE UPGRADED SPRUNG SLAT FRAME. NOTE THAT THESE PARTS ARE NOT TO BE FITTED IN THIS LUCIA SINGLE BED. Bolts (M6x15mm) Support leg HARDWARE NEEDED FOR DRAWER ASSEMBLY (PACK C)
-
Page 3: Additional Tools Required
Additional Tools Required Care & Maintenance In the unlikely event of missing or damaged parts, please contact the customer service team on 0344 292 00 00. When calling this number, please quote the part code reference numbers shown in this leaflet when requesting spare or replacement parts. - Page 4 Bed Assembly - Use Pack 'A' NOTE THAT THE DRAWER CAN BE FITTED ON THE LEFT or THE RIGHT SIDE OF THE BED - CHOOSE WHICH SIDE YOU WANT THE DRAWER & FIT SIDE PANEL (3) IN THAT POSITION. Stage DRAWER ON RIGHT DRAWER ON LEFT 10mm...
- Page 5 Fitting Wooden Slat Set - Use Pack 'B' Stage Carefully lay wooden slat set (6) on the metal supports on each side panel. Using two bolts (E) with spring washers (V), flat washers (G) and sleeve nuts (F) fix one slat next to headboard.
- Page 6 Fitting Upgraded Sprung Slat Frame - Use Pack 'B' Stage Open the sprung slat frame and lay face down on the working surface. Carefully turn the slat frame over and position onto the metal slat supports on each side panel. Align the frame with the fixing holes at each end and secure using four sets of bolts (E), spring washers (V), flat washers (G) and sleeve-nuts (F).
- Page 7 Drawer Assembly - Use Pack 'C' Stage IMPORTANT: MAKE SURE WHEN FITTING THE NUTS THAT THE HOLE IS IN CORRECT ALIGNMENT WITH THE HOLE IN THE PANEL EDGE. iii: Page 7 of 8...
- Page 8 Drawer Assembly - Use Pack 'C & D' Stage Fit the assembled drawer to rear of Drawer Face Panel (10). Carefully follow the guide lines on inside face of the rear side. Stage SLIDE IN THE DRAWER Page 8 of 8...
