DREAMS LUGANO SINGLE BED Assembly Instructions

Assembly Instructions

NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that

the bed will be used in.

Before you

Start, here

is some

helpful advice

LUGANO SINGLE BED

1. We suggest you spend a short time reading through this leaflet and then

follow the simple step by step instructions.

2. If you follow the instructions carefully the end result should be worth the effort.

3. Do not discard any of the packaging until you have checked that you

have all the parts and the pack of fittings.

4. Assemble this product on a carpet.

5. To ensure an easier assembly, we strongly advise that all fittings are only

finger tightened during initial assembly. Only upon completion of the

assembly should all fixing points be fully tightened.

6. We recommend a periodic check on all fixing points to make sure they remain

fully tightened.

7. Keep glue and fittings out of children's reach.

In the unlikely event that this product has missing or damaged parts, please call

0870 3333 612

to obtain spares

1 of 4

Table of Contents

Need help?

Do you have a question about the LUGANO SINGLE BED and is the answer not in the manual?

Page 1 LUGANO SINGLE BED Assembly Instructions NOTE: It will require two people to assemble this bed. Assembly should be carried out in the room that the bed will be used in. 1. We suggest you spend a short time reading through this leaflet and then Before you follow the simple step by step instructions.
Page 2 Component parts and fittings contained in the box PARTS Fittings M6x35mm Bolt 6pcs 1 piece M6 Nut 6pcs 2 pieces 4MM Allen key 2 pieces 2 pieces 5MM Allen key 1 piece Spanner M8x100mmBolt 4pcs 2 of 4...
Page 3 ASSEMBLY 1) Fix the wooden legs (4) onto the headboard STEP 1 (1) & footboard (2) using bolt (F). 2) Loosen the bolts from the headboard (1) and footboard (2). NOTE: Merely loosen the bolts, do not take out. 1) Fit the side rail (3) to the head & STEP 2 Footboard (1&2) slotting the pre-fitted brackets together as shown.
Page 4 ASSEMBLY STEP 3 NOTE: Slats not supplied shown for reference only. Both slats on “step 3---step 4” can be assembled to the bedstead. you can to make a choice between the two slats. 1) Carefully locate the slats frame onto the bed.
