VGE Xclear IMMERSION UV-C 40W AMALGAM Manual page 9

REPLACING/MAINTAINING IMMERSION UV-C LAMP
The lamp must be replaced after 8.000 or 16.000 (amalgam) operating hours and the quartz
glass must be cleaned.
Drawing 1
1. For your own safety, put on the supplied UV safety goggles (A)
2. Wear the supplied gloves (B)
3. De-energize the appliance and wait at least 10 minutes
4. Carefully take the Immersion UV-C out of the appliance/machine
5. Loosen the nut (I) from the screw part (H)
6. Carefully pull the lamp (C) off the lamp fitting (F)
7. Take a new UV lamp (C) out of the packaging
8. Carefully slide the lamp (C) into the quartz glass (D)
9. Place the lamp fitting (F) on the lamp (C)
10. If necessary, clean the quartz glass with a soft cloth and a non-aggressive cleaning agent.
When the quartz glass is totally dry you can check for lime scale deposits. Remove any lime
scale deposits with appropriate lime scale removers (i.e. cleaning vinegar).
11. Slide the lamp fitting into the quartz glass and hand-tighten the nut (I) onto the screw part
(H). This will ensure that the O-ring (J) is locked in and that the connection is therefore
watertight.
12. The UV-C appliance is now ready for use
TECHNICAL DATA
Model 40W
Article number 3100860
T5 lamp 40 Watt
Lamp life 8000 hours
Supply voltage 230V AC
50/60Hz
Length of 85 cm
luminaire +
quartz glass
75W 40W Amalgam
3100862 3100864
75 Watt 40 Watt
8000 hours 16000 hours
230V AC 230V AC
50/60Hz 50/60Hz
85 cm 55 cm
80W Amalgam
3100866
80 Watt
16000 hours
230V AC
50/60Hz
85 cm
XCLEAR IMMERSION UV-C MANUAL |
EN
9
