  • Page 1 VENUE D-Show Sidecar Guide ™ for VENUE D-Show Systems PN 9321-62798-00 REV A 08/10...
  • Page 2 TL Fauxlder, TL In Tune, TL MasterMeter, TL Metro, TL Space, TL Utilities, Transfuser, Trillium Lane Labs, Vari-Fi Velvet, X-Form, and XMON are trademarks or registered trademarks of Avid Technology, Inc. Xpand! is Registered in the U.S. Patent and Trademark Office. All other trademarks are the property of their respective owners.
  • Page 3: Table Of Contents

    VENUE D-Show Sidecar ............... . . 2 Chapter 2. Connecting and Configuring a VENUE D-Show Sidecar .
  • Page 4 VENUE D-Show Sidecar...
  • Page 5: Chapter 1. Overview

    Chapter 1: Overview ® Each VENUE D-Show Sidecar adds 16 input channels to the Water and Moisture VENUE D-Show Main unit console. VENUE components should be operated away from sources of A total of three Sidecars can be connected to the D-Show Main direct moisture and should be kept clear of liquids that might unit, for a maximum of 56 Input Channel faders.
  • Page 6: Venue D-Show Sidecar

    VENUE D-Show Sidecar D-Show Sidecar Top Panel Encoder Assignment Section Input Channel Section Global Modifier Fader Bank switches D-Show Sidecar top panel Input Channel Section Global Modifier and Fader Bank Switches Each D-Show Sidecar has 16 channel strips that provide access Each D-Show Sidecar has a set of Global Modifier and Fader to Input Channels.
  • Page 7 D-Show Sidecar Back Panel Light port Power switches AC power connectors Console Link In and Out connectors Termination switch D-Show Sidecar back panel Console Link In and Out Connectors The Console Link In and Out connectors use 110-Ohm AES/EBU (Digital) XLR cables to connect the Sidecar to the D-Show Main unit or to other Sidecars.
  • Page 8 VENUE D-Show Sidecar...
  • Page 9: Chapter 2. Connecting And Configuring A Venue D-Show Sidecar

    On the last Sidecar only, terminate the Console Link connection with the Terminate switch. Termination switch Termination switch Termination switch set to “Thru” set to “Thru” set to “Terminate” Console Link connections for Main Unit (left) and Sidecars (right) Chapter 2: Connecting and Configuring a VENUE D-Show Sidecar 5...
  • Page 10: Configuring The Main Unit And Sidecars

    (one Sidecar and one Main Unit) where the Side- car is at the left of the Main Unit, the Main Unit should be set to Bus ID 2. • Set the ID of other units to match the layout of input channels. VENUE D-Show Sidecar...
  • Page 11: Attaching The D-Show Main Unit And Sidecars (Optional)

    • Small, flat head screwdriver for lifting top panels The process of attaching D-Show consoles will at times require two or more people to move the console. Removing screws from top panels Chapter 2: Connecting and Configuring a VENUE D-Show Sidecar 7...
  • Page 12 Do not tighten the screws. Screw holes Disconnecting cables to the top panels Remove each top panel from the facing side of each unit. Location of screw holes for attaching units Sidecar with top panels removed from right side of unit VENUE D-Show Sidecar...
  • Page 13 Philips screws on the raised section and eight pan head Philips screws with lock washers on each side. Attaching brackets to the bottom of the units Chapter 2: Connecting and Configuring a VENUE D-Show Sidecar 9...
  • Page 14 VENUE D-Show Sidecar...
  • Page 15: Appendix A. Compliance Information

    For more information about where you can drop off declare under our sole responsibility that the product your waste equipment for recycling, please contact your local city recycling office VENUE D-Show Sidecar or the dealer from whom you purchased the product. complies with Part 15 of FCC Rules.
  • Page 16: Safety Compliance

    12) For products that are not rack-mountable: Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the equipment. When a cart is used, use caution when moving the cart/equipment combination to avoid injury from tip-over. VENUE D-Show Sidecar...
