  • Page 1 Installing a Collaboration System on the Premier Cart...
  • Page 2 Bose is a registered trademark of Bose Corporation. The information contained in this document is subject to change without notice. Polycom assumes no responsibility for technical or editorial errors or omissions that may appear in this document or for the use of this material.

  • Page 3: Before You Start

    Europe) on the Premier Cart, or it may tip over. ❑ Power cables and polarity - Use power cables and adapters supplied by Polycom. Others may not have the correct polarity or power ratings and may cause damage.

  • Page 5: About This Booklet

    VCR or other optional equipment. If your iPower 900 Series Collaboration System is a dual-monitor system, see the i P o w e r 900 S e r i e s C o lla b o r a t i o n Sys t e m Admi n is t r a t o r ’ s G u id e for complete information about installing the system on the cart when you have two monitors.
  • Page 6 I N STA LL I N G A C O LL A B O RATI ON S Y STE M ON T H E P RE M IER CART To set up the Premier Cart, you will need: ❑ Phillips screwdriver ❑...
  • Page 7 R e m o vi n g t h e P r e mi e r Ca r t f r o m t h e P all e t While the Premier Cart is still on the pallet, remove the plastic wrap Removing the surrounding it.

  • Page 8: Removing The Shipping Brackets

    I N STA LL I N G A C O LL A B O RATI ON S Y STE M ON T H E P RE M IER CART Removing the Shipping Brackets To remove the shipping brackets: 1. Use a 1/2-inch socket wrench to unbolt the orange shipping brackets that secure both sides of the Premier Cart to the pallet.

  • Page 9: Installing The Monitor

    I n s t alli n g t h e C o mp u t e r B o x The computer box is shipped in its own carton. Once you unpack the Installing the computer box, you can install it in the Premier Cart. Computer Box To install the computer box on the bottom shelf: 1.
  • Page 10 I N STA LL I N G A C O LL A B O RATI ON S Y STE M ON T H E P RE M IER CART Installing the Front Bracket on the Monitor To install the front bracket on the cart: 1.
  • Page 11 I n s t alli n g t h e M o n i t o r To install the back brackets for the 27-inch (29-inch in Europe) monitor: 1. Determine which size monitor you have. If you have a 32-inch (34-inch in Europe) monitor, go to the “Installing the Back Brackets for the 32-inch (34-inch in Europe) Monitor”...
  • Page 12 I N STA LL I N G A C O LL A B O RATI ON S Y STE M ON T H E P RE M IER CART Installing the Back Brackets for the 32-inch (34-inch in Europe) Monitor Before you begin, note that you must follow these instructions e xa c t ly to ensure that the monitor is installed safely.
  • Page 13 I n s t alli n g t h e M o n i t o r Positioning the Monitor on the Premier Cart When you have completed the installation of the brackets on your Premier Cart, you are ready to install the monitor. Note: Do not install a monitor larger than 32-inches (34-inches in Europe) on the Premier Cart.
  • Page 14 I N STA LL I N G A C O LL A B O RATI ON S Y STE M ON T H E P RE M IER CART Sticking the Velcro Straps onto the Monitor The Velcro straps help secure your monitor to the cart. To stick the Velcro straps onto the monitor: 1.

  • Page 15: Connecting The Audio Cables

    C o nn e c t i n g t h e Ca b l e s Now that the monitor is attached to the cart, you must place the Connecting the camera on the monitor and connect it. See the document that you Cables received with your camera for instructions on how to attach the camera to the monitor.
  • Page 16 I N STA LL I N G A C O LL A B O RATI ON S Y STE M ON T H E P RE M IER CART 3. Plug another end of the black Y-adapter cable into the audio cable from the Bose speaker The audio cable from the Bose speaker is located on the inside of the Premier Cart.
  • Page 17 C o nn e c t i n g t h e Ca b l e s To connect the audio cables when you have an iPower 70 camera: 1. At the back of the collaboration system, plug the orange end of the audio output cable into the orange LINE OUT connector the computer box.
  • Page 18 I N STA LL I N G A C O LL A B O RATI ON S Y STE M ON T H E P RE M IER CART Connecting the Monitor’s Power Cable The monitor’s power cable connects to the Premier Cart with a power adapter cable.
  • Page 19 C o nn e c t i n g t h e Ca b l e s Connecting the Computer Box Power Cable To connect the computer box power cable: 1. Plug the power cable that was shipped with your cart into the power receptacle on the computer box.

  • Page 20: Service And Support

    (71 centimeters) wide if you push it from its side. For support or service, please contact your Polycom service Service and provider or call Polycom Technical Support. You can find phone Support numbers for Technical Support in your area at the Polycom web site, www.polycom.com.
