Summary of Contents for Instron 3119-600 Series
- Page 1 3119-600 Series Temperature Controlled Chambers Reference Manual - Pre-Installation M55-16546-EN Revision E The difference is measurable ®...
- Page 2 Instron is a registered trademark of Illinois Tool Works Inc. (ITW). Other names, logos, icons and marks identifying Instron products and services referenced herein are trademarks of ITW and may not be used without the prior written permission of ITW.
-
Page 3: Table Of Contents
Material Safety Data Sheets ..........Product Support: www.instron.com... - Page 4 Preliminary Pages M55-16546-EN...
-
Page 5: Chapter 1 Introduction
The purpose of this manual is to provide you with information that will assist you in creating the conditions for a trouble free installation of your Instron® 3119-600 series chamber. The chamber models covered and their options are discussed in the different sections of this manual. -
Page 6: Additional Chamber Documentation
Supplement M55-17038-MU “Using Instron Furnaces and Environmental Chambers”. If you do not have a copy of this supplement, contact your local Instron representative. Operating instructions for the chamber are supplied with the chamber and contain... -
Page 7: Preparing For Installation
Use this chapter where the installation and commissioning of the chamber is carried out by an Instron engineer. This chapter defines your responsibilities and the responsibilities of Instron for this type of installation. Instron recommends that you do not undertake your own installation. -
Page 8: Handling
Customer Installation Task Responsibility Mounting standalone chamber. Customer Mounting chamber to a new Instron test system, where Instron provide the Instron brackets. Making all electrical connections from mains to chamber. Instron Making cryogenic supply connections to chamber, where Instron provide Instron Dewar flask/gas bottles/hose *. -
Page 9: Unpacking And Transporting
Crush Hazard - Use good practice when lifting by crane, hoist or fork-lift truck. Keep loads as low to the ground as possible. Any crane, hoist or fork-lift truck used to transport the equipment must have an adequate load capacity. Product Support: www.instron.com... -
Page 10: Unpacking
To protect the underside of the chamber, it is supplied mounted on four screws. Leave these screws in place. The Instron engineer will remove the screws at the point when the chamber is mounted on its load frame brackets or roller frame wheels. -
Page 11: Transporting The Chamber
Transport the chamber using a crane, hoist or forklift truck according to good working practice. If lifting the chamber from above, Figure 1 (and Table 1) illustrates the lifting points. Rear of Chamber Front of Chamber Figure 1. Chamber Fixing Holes/Lifting Points (viewed from above or below) Product Support: www.instron.com... - Page 12 Chapter: Unpacking and Transporting Table 1. Chamber Fixing Holes/Lifting Points Dimensions - mm (in) Chamber Number 3119-605 6 x M10 (12.8) (2.9) (13.2) (5.1) (8.1) 3119-606 6 x M10 (12.8) (2.9) (13.2) (5.1) (8.1) 3119-609 6 x M10 (12.8) (2.9) (13.2) (5.1) (8.1)
-
Page 13: Guidelines For Final Positioning Of The Chamber Test System
Guidelines for Final Positioning of the Chamber Test System This section assumes that the chamber is part of a new Instron test system. The chamber may have a fixed mount or a roller mount assembly. The chamber may also be fitted with a cooling pack option. - Page 14 Chapter: Unpacking and Transporting Cryogenic Gas Cryogenic Gas Supply Hose Exhaust Hose Controller Position Chamber (in fully retracted position) Typical EM Load Frame Footprint Door Open Position Typical EM Load Frame Column Figure 2. Plan View of Chamber with 3119-230 Roller Mount Assembly M55-16546-EN...
- Page 15 Transporting the Chamber Cryogenic Gas Cryogenic Gas Supply Hose Exhaust Hose Typical EM Load Frame Footprint Controller Position Chamber Typical EM Load Frame Column Figure 3. Plan View of Chamber with Fixed Mounting Product Support: www.instron.com...
- Page 16 Chapter: Unpacking and Transporting Table 2. Chamber Footprint Dimensions Dimensions - mm (in) Chamber Number Minimum Minimum Minimum 3119-605 1317 (51.9) (11.8) (13.8) (27.6) (35.7) (24.3) (16.8) (17.7) 3119-606 1317 (51.9) (11.8) (13.8) (27.6) (35.7) (24.3) (16.8) (17.7) 3119-609 1317 (51.9) (11.8) (13.8)
-
Page 17: Chamber Mounting Kit Compatibility
Prevent the moving grip driving into the chamber. • Provide a minimum clearance of 30 mm to prevent fingers from becoming trapped between moving components. Commissioning After installation, the Instron engineer will check the performance of the chamber and provide the contractually agreed training. Product Support: www.instron.com... -
Page 18: Information For Customer Installation Only
Chapter: Unpacking and Transporting Information for Customer Installation Only Instron recommend that customers do not undertake chamber installation and accept no responsibility for such an installation. In the event that you decide to undertake your own installation, the following watch points are offered without prejudice: •... -
Page 19: Specifications
Material Safety Data Sheets......... . 32 K* = Light as shown (right hand side) is for models 3119-605, 606 and 609 only. For models 3119-607, 608 and 610 light is on left hand side Figure 4. Chamber Dimensions Product Support: www.instron.com... -
Page 20: Physical Data
Chapter: Specifications Physical Data Referring to Figure Table 4. External dimensions Bottom Control External External Top Hinge Hinge Panel External Handle Width - Height - Height - Height- Depth - Depth - Depth - mm (in) mm (in) mm (in) mm (in) mm (in) mm (in) - Page 21 (29.9) (15.7) (15.7) 3119-618 1000 20 (0.8) (39.3) (15.7) (15.7) a. As shown in Figure 4, light is on right hand side of chamber Light is on left hand side of chamber. Not shown in Figure 4 Product Support: www.instron.com...
- Page 22 Chapter: Specifications Table 6. Pullrod dimensions Centre of Pullrod Port to Front of Chamber Centre of Pullrod Port to Space Rear of Chamber Space Pullrod Port Diameter mm (in) mm (in) mm (in) 3119-605 110 (4.3) 120 (4.7) 67 (2.6) 3119-606 110 (4.3) 120 (4.7)
- Page 23 3119-616 460 (18.1) 125 (4.9) 3119-617 460 (18.1) 125 (4.9) 3119-618 460 (18.1) 125 (4.9) Table 8. Cable and hose clearances Cable Clearance Hose Clearance mm (in) mm (in) All variants Minimum 200 (7.9) Minimum 300 (11.8) Product Support: www.instron.com...
- Page 24 Chapter: Specifications Table 9. Weight Weight kg (lb) 3119-605 65 (143) 3119-606 65 (143) 3119-609 75 (165) 3119-615 85 (187) 3119-607 135 (297) 3119-608 165 (363) 3119-610 165 (363) 3119-616 165 (320) 3119-617 150 (309) 3119-618 173 (382) M55-16546-EN...
-
Page 25: Operating Performance
The specified performance of the chamber is not applicable within 15°C of ambient. b. Figures for temperature measured at the specimen (metal) over a 50 mm (2 in) gauge length. Figures are not applicable within 15°C of ambient. Product Support: www.instron.com... - Page 26 Chapter: Specifications Table 11. Heating and cooling specifications Heat-up Heat-up Heat-up Heat-up Time Time Time Cool- Time 120V a 200V a 240V a Down 100V a (minutes) (minutes) (minutes) Time a Heating (minutes) (minutes) Method 3119-605 Forced Convec- tion 3119-606 3119-609 3119-615 3119-607...
- Page 27 Based on a 3119-610 chamber containing typical 25 kg grips and pull rods such as 2716-002. Total gas consumption will be affected by the duration and frequency of door opening. It will also vary according to the size of the load string and specimen. Product Support: www.instron.com...
-
Page 28: Electrical Supply
Chapter: Specifications Electrical Supply Single phase 50/60 Hz ac supply (see Table 14) terminating in a socket (see Table 15), protected by a circuit breaker or fused isolator of an appropriate rating. Earth impedance = 1 Ω (tested prior to installation). Table 14. -
Page 29: Port Plugs
If Instron is supplying the load string, port plugs may also be supplied. Check your order to see if port plugs are included. If you are supplying your own port plugs, you need to ensure that the material used is suitable for the full temperature range in use and that friction is not introduced. - Page 30 Chapter: Specifications Table 16. Cryogen Connectors Coolant Chamber Typical Dewar Fitting Recommended Recommended Fitting Hose Dewar Flask ” BSP ” BSP 3119-104 3119-102 Male Male/Female CGA 295 Male 3119-106 (0.75-16 UNF -2A ” BSP 0.860” x ” 3119-103 Male Whitworth RH Male CGA 320 Male 3119-105 (0.825-14 NGO - RH)
- Page 31 Exhaust port outside diameter 31.75 (1.25) (mm (in)) inside diameter 25.4 (1) (mm (in)) Exhaust tubing outside diameter 39 (1.54) (supplied) (mm (in)) inside diameter 30 (1.18) (mm (in)) length 3000 (118.11) (mm (in)) material white silicon rubber Product Support: www.instron.com...
-
Page 32: Material Safety Data Sheets
Chapter: Specifications Material Safety Data Sheets This section contains information to allow you to obtain current Material Safety Data Sheets (MSDS) directly from the manufacturers. Instron is not responsible for the content or accuracy of these MSDSs. Material Location Manufacturer MSDS information... - Page 33 Paper MSDS No: 357 To confirm this is the most up to date MSDS for the product, visit the web page [www.thermalceramics.com] Where option is fitted to Contact your local supplier for information on your chamber. material safety. Product Support: www.instron.com...
- Page 34 Chapter: Specifications M55-16546-EN...
- Page 36 Product Support: www.instron.com...
