this threading to 63mm. You can turn the unions of the eccentric fittings to position them
exactly on the in/outlet of the filter. The in/outlet of the Flow-Matic is Ø 63 mm. When your
pipe system is smaller than 63 mm you can use the supplied reducers (Ø 63 x Ø 50 mm).
You can dismantle the system, with the unions (3).
2. Place the touch-screen controller with the pipe clips (4) on the pipework near the Flow-
Matic system.
3. Connect the cables to the automatic valves with the cable connectors (5). These
connectors will only fit one way. The cables are labelled with numbers for the
corresponding valve.
4. Place the blower of your beadfilter on the check valve (6) of the Flow-Matic.
5. Remove the aluminium stand from its packing and mount the pipe clip to the stand with
the corresponding fasteners (15 figure 1). This stand supports the system so the weight of
the installation is not on the pipework and the beadfilter connections. Position the pipe
clip to the correct height by sliding it up/down inside the rail and fasten it with the hex bolt.
Put the pipe clip with nut on the bolt and fasten it. Attach the pipe clip to the Flow-Matic.
ELECTRICAL CONNECTION
1. Connect the plug of the circulation pump to terminal 1 (7) of the controller. Blue Eco pump
users can connect a RJ45 Ethernet cable to the female RJ45- connector (9) of both the
controllers.
2. Connect the blower to terminal 2 (8) of the controller.
3. Connect the lead of the Flow-Matic to a mains outlet that is connected according to the
locally applicable standards and laws, with a properly earthed connection protected by a
residual-current device (see also the important safety instructions.
FUSE
The fuse (10) on the side of the controller protects the controller and other components
against short circuits and overload. If the system is shut down (i.e. the pump does not work and
the touchscreen does not light up) due to a short circuit or overload, the fuse can be replaced.
Always switch off the supply voltage before replacing the fuse. Replace the fuse with the same
type: 12A slow blow.
