CY4502 EZ-PD

CY4502 enables designers to evaluate the functionality of EZ-PD

controllers in Type-C EMCA (Electronically Marked Cable Assembly) cables

• Download and install the latest Kit Setup CY4502Setup.exe from

www.cypress.com/CY4502

• Unpack the kit contents and verify that all jumpers on the kit are set to the

default setting

LED1

CCG2

SWD Header

Type-C Plug

CY4502 bumpers are designed to work with CCG1 host and client demo boards.

Please ensure that the CY4502 board rests on a rm base while operating it with

other setups. This is to avoid stress on the CY4502 PCB and Type-C connectors.

CCG2 DEVELOPMENT KIT

20-pin Header

Default Jumper Settings

Jumper

J8, J13

J13

SWD Header

Setting

Open

Closed

1 - 2

Open

CCG2

LED2

Type-C Plug

Table of Contents

Need help?

Do you have a question about the CY4502 and is the answer not in the manual?

Page 1 CY4502 bumpers are designed to work with CCG1 host and client demo boards. Please ensure that the CY4502 board rests on a rm base while operating it with other setups. This is to avoid stress on the CY4502 PCB and Type-C connectors.
Page 2 • Connect CY4502 between a Type-C enabled host (e.g. Laptop, PC) and a Type-C enabled device with a Type-C receptacle (e.g. Monitor, USB hard disk). LED on the CY4502, closer to the host glows to indicate that the CY4502 board is powered. CY4502 is now functioning as a Type-C EMCA cable •...
