- Page 1 User’s Manual XS550 Temperature Measurement Module IM 01W06F02-01EN IM 01W06F02-01EN 1st Edition...
-
Page 2: Table Of Contents
8. General Specifications ................8-1 8.1 Standard Specifications ..................8-1 8.2 MODEL AND SUFFIX CODES ................8-4 8.3 Optional Accessories ....................8-4 8.4 Outline ........................8-5 8.5 Regulatory Compliance Statements ..............8-8 Revision Information ..................i 1st Edition: July 2020 All Rights Reserved, Copyright © 2020, Yokogawa Electric Corporation... -
Page 3: Introduction
(Hereinafter simply referred to as XS550). The XS550 works by utilizing XS110A Wireless Communication Module (Hereinafter simply referred to as XS110A). The XS550 is powered by the battery built-in the XS110A. Please install XS110A before use. Table 1.1 lists the documents related to this manual. - Page 4 Regarding This Manual • This manual should be provided to the end user. • This manual and the identification tag attached on the packing box are essential parts of the product; keep them in a safe place for future reference. • The contents of this manual are subject to change without prior notice. • All rights reserved. No part of this manual may be reproduced in any form without Yokogawa’s written permission. • Yokogawa makes no warranty of any kind with regard to this manual, including, but not limited to, implied warranty of merchantability and fitness for a particular purpose. • If any question arises or errors are found, or if any information is missing from this manual, please inform the nearest Yokogawa sales office. • The specifications covered by this manual are limited to those for the standard type under the specified model number break-down and do not cover custom-made instruments. When products whose suffix code or...
- Page 5 NOTE Draws attention to information essential for understanding the operation and features. : Functional grounding terminal n Trademarks • Sushi Sensor is a registered trademark of Yokogawa Electric Corporation. • The registered trademarks or trademarks of the respective companies in the text do not bear the mark of TM or ®. IM 01W06F02-01EN...
-
Page 6: Safe Use Of The Product
If these instructions are not heeded, the protection provided by this instrument may be impaired. In this case, Yokogawa cannot guarantee that the instrument can be safely operated. Please pay special attention to the following... - Page 7 <Introduction> (d) Maintenance • Please do not carry out except being written to maintenance descriptions. When these procedures are needed, please contact nearest YOKOGAWA office. • Care should be taken to prevent the buildup of drift, dust or other material on the name plate. In case of its maintenance, soft and dry cloth is used. (e) Modification • Yokogawa will not be liable for malfunctions or damage resulting from any modification made to this instrument by the customer. (f) Explosion Protected Type Instrument •...
-
Page 8: Warranty
Problems occurring during the warranty period shall basically be repaired free of change. • If any problems are experienced with this product, the customer should contact the Yokogawa representative from which this product was purchased or the nearest Yokogawa office. • If a problem arises with this product, please inform us of the nature of the problem and the circumstances under which it developed, including the model specification and serial number. Any diagrams, data and other... -
Page 9: Notes On Handling
The XS550 is fully factory-tested before shipment. When the XS550 is delivered, check the appearance for damage and that all the components mentioned below are included. If the XS550 is ordered without the mounting bracket, the XS550 Mounting Parts will not be included. -
Page 10: Transportation
• The following temperature and humidity range are recommended. - Temperature: –40 to 85°C (–40 to 185°F) - Humidity: 0 to 100% RH (non-condensation) (2) When storing the XS550, repack it carefully in the packaging that it was originally shipped with. NOTE When storing this product over a long period, it is recommended to put the instrument in OFF Mode to conserve the battery. -
Page 11: Restrictions On Use Of Radio Transceivers
Shock and Vibration It is designed to be resistant to shock and vibration. However, it is recommended that XS550 be installed in a location that is subject to a minimum amount of impact and vibration. Restrictions on Use of Radio Transceivers... -
Page 12: Explosion Protected Instrument
Li: 0 µH Lo: 150 mH Lo ≥ Li IS Apparatus (3) Ui, Ii, Pi, Ci, Li or Simple Apparatus XS550 IS Apparatus (1) (connected to Terminal 1, 2) Temperature measurement module and / or IS Apparatus (4) Ui, Ii, Pi, Ci, Li... - Page 13 Case and the earth point (or the equipotential bonding system). Installation: The equipment must be installed in accordance with EN 60079-14, local requirements, and the control drawing. Maintenance and repair: WARNING Only personnel authorized by Yokogawa Electric Corporation can repair the equipment. 2.6.2 IECEx Intrinsic Safety Technical data: • Certificate number: IECEx DEK 19.0027X • Applicable standards: I EC 60079-0 Ed. 7.0 (2017), IEC 60079-11 Ed. 6.0 (2011)
- Page 14 Li: 0 µH Lo: 150 mH Lo ≥ Li IS Apparatus (3) Ui, Ii, Pi, Ci, Li or Simple Apparatus XS550 IS Apparatus (1) (connected to Terminal 1, 2) Temperature measurement module and / or IS Apparatus (4) Ui, Ii, Pi, Ci, Li...
- Page 15 <Notes on Handling> Installation: The equipment must be installed in accordance with IEC 60079-14, local requirements, and the control drawing. Maintenance and repair: WARNING Only personnel authorized by Yokogawa Electric Corporation can repair the equipment. IM 01W06F02-01EN...
-
Page 16: Component Names
<Component Names> 3. Component Names Input terminal Ground terminal XS110A connector XS110A fixed screw Tag plate hanging hole Ground terminal Input terminal XS110A fixed screw XS110A connector F04.ai IM 01W06F02-01EN... -
Page 17: Installation
To protect the connector, use a protective cap (Part Number: F9097ND) when replacing batteries or installing without XS110A. The protective cap is used to temporarily protect the XS550 connector when the XS110A is removed from the XS550 during battery replacement and other operations. When the XS110A is removed, waterproof and dustproof performance cannot be guaranteed. - Page 18 Fit the XS110A into the XS550. Turn the XS110A fixing screws attached to the XS550 one by one to the left, pull them out, and turn them 1/4 left from where they come into contact to tighten them. At this time, check that the head of the XS110A fixing screw is flush with the surface of the XS110A. Turn the XS110A measuring module fixing screw to the right. At this time, tighten the screws. Set the torque to 1.4 N·m. After the XS110A has been installed, the settings can be made using the Sushi Sensor App. First, make sure that the Sushi Sensor has the latest firmware. To remove, follow the same procedure as for mounting. If it is difficult to pushup the XS110A and XS550 by hand, you can easily pushup them by pushing a flat blade screwdriver in between the grooves of the XS110A and XS550. IM 01W06F02-01EN...
- Page 19 2-inch pipe XS550 mounting bolt F06.ai n Mounting procedure for vertical 2-inch pipe Mount the XS550 to the mounting bracket using the XS550 mounting bolts with a torque of 1.4 N·m. Mount the mounting bracket to the 2-inch pipe using the U-bolt. IM 01W06F02-01EN...
- Page 20 XS550 mounting bolt F07.ai n Mounting procedure for horizontal 2-inch pipe Mount the XS550 to the mounting bracket using the XS550 mounting bolts with a torque of 1.4 N·m. Mount the bracket to the 2-inch pipe using the U-bolt. Use the horizontal pipe mounting screws to secure the mounting bracket with a torque of 1.4 N·m.
- Page 21 Mounting bracket belt Pipe XS550 mounting bolt F08.ai n installation procedure Mount the XS550 to the mounting bracket using the XS550 mounting bolts with a torque of 1.4 N·m. Using a belt, attach the XS550 mounting bracket to the pipe. IM 01W06F02-01EN...
-
Page 22: Wiring
<Wiring> 5. Wiring Precautions in Wiring CAUTION Ensure continuity (Resistance less than 0.2 MΩ) between the sheath (Element) of the thermocouple to be connected and the grounding pole. Grounding resistance 100 Ω or less is recommended. IMPORTANT • Be sure to waterproof the threaded area. (For waterproofing, we recommend silicone resin non-curing sealant.) • Avoid wiring noise sources such as large capacity motors or power Power supply. Cable Selection Only thermocouples can be used for the temperature sensor. A compensating conductor (Refer to IEC584-3 Compensating Conductor for Thermocouples) corresponding to the type of thermocouple is used. -
Page 23: Connecting Cables To Terminals
<Wiring> n Applicable Cables Insulated cables for industrial equipment such as; • 600 V polyvinyl chloride insulated wires (IV): JIS C3307 • Polyvinyl chloride insulated wires for electrical apparatus (KIV): JIS C3316 • 600 V grade heat-resistant polyvinyl chloride insulated wires (HIV): JIS C3317 • Heatproof vinyl insulated wires VW-1 (UL 1015/UL 1007) Wire size • Core: AWG 14 to 13 (2 to 2.6 mm Termination • Use a round crimp terminal for M4 terminals with an insulation sleeve Connecting Cables to Terminals 5.3.1 Connection of the input terminal Ground terminal F09.ai Figure 5-1 Input Terminal Connections If the cable has a screen for shielding, connect the screen to the ground terminal shown in Figure 5-1. Be careful not to make the screen as a multi- point grounding. - Page 24 F10.ai Thermocouple 2 (–) F11.ai Figure 5-2 XS550 Input terminal wire connection diagram Prepare a cable ground that matches the electrical connection you ordered. When ordering the M20 female of the electrical connection, tighten the cable gland. Let the k be about 2 N·m. 1/2 NPT female of the electrical connection is ordered, a thread conversion adapter with a hexagonal external shape is mounted shown in Figure 5-3.
- Page 25 <Wiring> IMPORTANT Be sure to waterproof the threaded area of the cable gland (For waterproofing, we recommend silicone resin type non-curing sealant.). n Input Terminal Input terminal is a spring terminal. While pushing the lever on the upper part of the input terminal Plug in the cable. To remove the cable, push the lever in. while pulling out the cable. Do not use stick terminals as there is a risk of short- circuiting between adjacent terminals.
- Page 26 When replacement to different type of temperature sensor, it is necessary to change the parameters related to the sensor type. For setting method, refer to "Sushi Sensor Series Software Edition" (IM01W06C01-01EN). XS550 supports the following sensor types. Thermocouples: B, E, J, K, N, R, S, T, C Check the connection between the input terminal and thermocouple, and set the correct sensor type and number of connections.
-
Page 27: Grounding
Figure 5-6 or Figure 5-7. Grounding resistance 100 Ω or less is recommended. If continuity between the ground terminal and the ground electrode cannot be ensured, use the cable described in Section 5.2. Do not share the ground wiring of the XS550 with other devices . Ground terminal Ground terminal F15.ai... -
Page 28: Operation
Mount the XS110A before using the product. Refer to 4.2.1 "Mounting with XS110A" for mounting method of XS110A. (1) Checking Installation and wiring Ensure that the XS550 is installed correctly and the temperature sensor is connected correctly according to the procedures described in section 4 “Installation”, and section 5 “Wiring”. -
Page 29: Zero Point Adjustment
<Operation> Zero Point Adjustment IMPORTANT Do not remove the XS110A and XS550 after performing a zero point adjustment. Powering off within 30 seconds of performing this procedure will return the zero point to its previous setting. When the input sensor is set, the adjustment amount of the zero point is automatically calculated based on the value obtained at the time of shipment from the factory. -
Page 30: Maintenance
Remove the XS110A from the XS550 (Refer to Chapter 4). Attach the battery to the new XS110A. Install the new XS110A on the XS550 (Refer to Chapter 4). Refer to the XS110A User’s Manual (IM01W06D01-01EN) for details on installing batteries in the XS110A. -
Page 31: Replacing The Xs550
Configure the XS550 network settings. Return the XS550 to the installed state (Refer to Chapter 4). How to set up XS550 and use the Sushi Sensor App are described in the Sushi Sensor series. Refer to the Sushi Sensor Series Software Edition (IM01W06C01-01EN). -
Page 32: General Specifications
<General Specifications> 8. General Specifications Refer to GS 01W06F02-01EN for the latest information. Standard Input Signal Source Resistance: Specifications 1 kΩ or less Zero Point Adjustment: n Measurement Range Conducted by Sushi Sensor App. Refer to Table 1 Diagnostic Function: Terminal block temperature error, n PERFORMANCE memory failure, setting sensor SPECIFICATIONS failure, sensor measurement... - Page 33 <General Specifications> n PHYSICAL SPECIFICATIONS Wire connection port: M20 female, 1/2 NPT female Housing: stainless steel Wight: 400 g (0.88 lb) Mounting: Refer to “MODEL AND SUFFIX CODES.” Table 8.1 Sensor Type, Measurement Range, and Accuracy Sensor Type Standard Measurement Range Accuracy 100 to 300°C (212 to 572°F) ±...
- Page 34 <General Specifications> Table 8.2 Effects of Ambient Temperature Temperature Effects per 1.0°C Sensor Type Change in Ambient Measurement Range Temperature 0.092°C – (0.032% of (t –100)) 100°C ≤ t < 300°C 0.025°C – (0.0010% of (t –300)) 300°C ≤ t < 1000°C 0.029°C 1000°C ≤ t < 1820°C 0.00099°C – (0.0040% of t) –200°C ≤ t < 0°C 0.00099°C + (0.0019% of t) 0°C ≤ t < 1000°C 0.0012°C – (0.0041% of t) –200°C ≤ t < 0°C 0.0012°C + (0.0019% of t) 0°C ≤ t < 1200°C 0.0015°C – (0.0048% of t) –200°C ≤ t < 0°C 0.0015°C + (0.0023% of t) 0°C ≤ t < 1372°C 0.0023°C –...
-
Page 35: Model And Suffix Codes
* The protective cap is used to temporarily protect the connector of the product when the XS110A is removed from XS550 for battery replacement, etc. When the XS110A is removed from the product, waterproof and dustproof performance cannot be guaranteed. -
Page 36: Outline
<General Specifications> Outline l 2-inch Horizontal Pipe Mounting Unit: mm (approx. inch) 103 (4.06) XS110A Wireless ø68 (2.68) Communication Module (1.38) XS110A fixed screw Mounting bracket 2-inch pipe (0.87) (1.1) (1.77) (2.72) (1.34) F17.ai IM 01W06F02-01EN... - Page 37 <General Specifications> l 2-inch Vertical Pipe Mounting 103 (4.06) XS110A Wireless ø68 (2.68) Communication Module (1.38) XS110A fixed screw (1.34) Mounting bracket 2-inch Pipe 52.5 (2.07) F18.ai 105 (4.13) IM 01W06F02-01EN...
- Page 38 <General Specifications> l Terminal Layout XS110A connector F19.ai l Connection of Input Terminal 1 input 2 input Thermocouple 1 Thermocouple 1 (–) (–) F20.ai Thermocouple 2 (–) F21.ai IM 01W06F02-01EN...
-
Page 39: Regulatory Compliance Statements
<General Specifications> Regulatory Compliance Statements This device satisfies the following standards. *: P lease confirm that an installation region fulfills an applicable standard. If additional regulatory information and approvals are required, contact a Yokogawa representative. CE Conformity: The Authorized Representative for this product in the EEA is: Yokogawa Europe B.V. Euroweg 2, 3825 HD Amersfoort, THE NETHERLANDS. RoHS Directive: EN50581 EMC Directive: EN61326-1 Class A Table 2, EN61326-2-3, EN55011 Class A CAUTION This instrument is a Class A product, and it is designed for use in the industrial environment. - Page 40 <General Specifications> The full text of the EU declaration of conformity is available at the following internet address: https://partner.yokogawa.com/global/ Canadian Safety Standards: CAN/CSA-C22.2 No.61010-1 CAN/CSA-C22.2 No.61010-2-030 CSA-C22.2 No.94.2 IEC 60529 Pollution degree 2 Overvoltage category I Degrees of Protection: IP66/IP67 and Type 4X Apply when connected to the XS110A.
-
Page 41: Revision Information
Revision Information Title : XS550 Temperature Measurement Module Manual No. : IM 01W06F02-01EN Edition No. Date Page Revision Item July 2020 New publication IM 01W06F02-01EN... - Page 44 Phone : 1-800-888-6400 Fax : 1-770-254-0928 YOKOGAWA EUROPE B. V. Euroweg 2, 3825 HD Amersfoort, THE NETHERLANDS Phone : 31-88-4641000 Fax : 31-88-4641111 YOKOGAWA ENGINEERING ASIA PTE. LTD. 5 Bedok South Road, Singapore 469270, SINGAPORE Phone : 65-6241-9933 Fax : 65-6241-9919 Printed in Japan...
