TABLE OF CONTENTS
HT40KX / Prop Ctrl / No Eng Ctrls (HRAAAA-P0**)
DESCRIPTION & SPECIFICATIONS
22343
INSTALLATION DIMENSIONS
18353
MOUNTING DIMENSIONS - BASE PLATE
22341
CAPACITY CHART - HT40KX
15394
VEHICLE & CRANE ELECTRICAL HAZARD INFORMATION
920612
SAFETY & HAZARDS - GENERAL
19217
WINCH SAFETY WARNINGS
22489
20697
CRANE INSTALLATION (PAGE 1 OF 2)
22344B
CRANE INSTALLATION (PAGE 2 OF 2)
CRANE OPERATION & MAINTENANCE INSTRUCTIONS (PAGE 2 OF 3)
CRANE OPERATION & MAINTENANCE INSTRUCTIONS (PAGE 3 OF 3)
22328
SAFETY SHUTOFF INSTRUCTIONS
22335
PTO INSTALLATION
20698
COMPARTMENT DRAWING
17831
INSTALLATION & MOUNTING DIMENSIONS - 17350 PEDESTAL
22245
MAINTENANCE & SERVICE
14544
ADJUSTMENT OF WORM HEIGHT AND BACKLASH
14553
ADJUSTMENT OF ROTATION WORM END PLAY
22346
HT40/50KX CRANE REPLACEMENT PARTS DRAWING
22517
HT40/50KX CRANE REPLACEMENT PARTS LIST
22518
HT40/50KX CRANE FASTENER LIST
24571
24550 BOOM (FULL POWER EXTENSION) REPLACEMENT PARTS DRAWING
24572
24550 BOOM (FULL POWER EXTENSION) REPLACEMENT PARTS LIST
20699
HYDRAULIC SYSTEM COMPONENTS REPLACEMENT PARTS DRAWING
20930
HYDRAULIC SYSTEM COMPONENTS REPLACEMENT PARTS LIST
22657
ELECTRICAL SCHEMATIC - PROPORTIONAL WITHOUT ENGINE CONTROLS
20353
ELECTRICAL SCHEMATIC - PROP W/ IN-COMP CONTROLS (NO ENGINE CONTROLS)
22488
HYDRAULIC SYSTEM SCHEMATIC - PROPORTIONAL CONTROL HT40/50KX
22655
PROPORTIONAL PENDANT CONTROL
22449
22450 ANTI-TWO-BLOCK SYSTEM
22684
22685 ANTI-TWO-BLOCK SYSTEM (IN BOARD - LH)
22448
TITLE
TABLE OF CONTENTS
MFG., INC.
CINCINNATI, OHIO
HT40KX (HRAAAA-P0**)
SECTION
DATE
1-19-04
-
20993
SUPERCEDES
-
Advertisement
Table of Contents
Related Manuals for Venturo HT40KX
Summary of Contents for Venturo HT40KX
-
Page 1: Table Of Contents
TABLE OF CONTENTS HT40KX / Prop Ctrl / No Eng Ctrls (HRAAAA-P0**) SECTION 100 DESCRIPTION & SPECIFICATIONS 22343 INSTALLATION DIMENSIONS 18353 MOUNTING DIMENSIONS - BASE PLATE 22341 CAPACITY CHART - HT40KX SECTION 150 SAFETY 15394 VEHICLE & CRANE ELECTRICAL HAZARD INFORMATION 920612 SAFETY &... -
Page 2: Section 100
SECTION 100 DESCRIPTION & SPECIFICATIONS 7607100A... -
Page 6: Section 150
SECTION 150 SAFETY 8604150... - Page 7 VEHICLE & CRANE MOUNTED ELECTRICAL HAZARD SIGN APPLICATION & INFORMATION ET & HT CRANE SERIES SIGN NO. 15393A DISPLAYS THE INTERNATIONAL SYMBOL FOR ELECTRICITY AND WARNS OF DANGER FROM AN ELECTRICALLY CHARGED VEHICLE, CRANE, OR LOAD. FOUR ARE RECOMMENDED (ONE FOR EACH SIDE AND ONE FOR EACH END OF VEHICLE) TO BE APPLIED IN LOCATIONS WHICH ARE READILY VISIBLE TO GROUND PERSONNEL.
- Page 8 CRANE SAFETY AND HAZARDS HT25KX, HT40KX, HT50KX CAUTIONS 1. INSPECT VEHICLE AND CRANE, INCLUDING OPERATION, PRIOR TO USE DAILY. 2. DO NOT USE THIS EQUIPMENT EXCEPT ON SOLID, LEVEL SURFACE WITH CRANE MOUNTED ON FACTORY-RECOMMENDED TRUCK. 3. BEFORE OPERATING THE CRANE, REFER TO MAXIMUM LOAD (CAPACITY) CHART ON CRANE FOR OPERATING (LOAD) LIMITATIONS.
-
Page 10: Decal Placement
DANGER ELEC. HAZARD 22499 KNOW 15391 YOUR DANGER SIGNALS (NOT PASSENGER LIFT) 22496 LARGE VENTURO 19788 14473-2 15390 PROPORTIONAL CONTROL GREASE CAUTION * PROPORTIONAL ONLY BOOM BACK SERIAL NO. 84030 & UP SERIAL NO. 85030 & UP TITLE DATE SECTION... -
Page 11: Section 200
SECTION 200 INSTALLATION 7607200A... -
Page 12: Crane Installation
The maximum combined overturning moment for the HT40KX is 45,000 ft. lbs. and for the HT50KX is 55,000 ft. lbs. The maximum vertical load for the HT40KX is 7900 lbs. and for the HT50KX is 9900 lbs. CRANE MOUNTING The crane base plate or mounting pedestal must be bolted to the body reinforcing plate with eight (8) grade five (5) bolts of 1"... - Page 13 The PTO pump should be sized to allow an engine idle speed range that will deliver approxi- mately 2.5 GPM for the HT40KX standard (non-proportional), 5.0 GPM for the HT40KX pro- portional, 3.0 GPM for the HT50KX standard or 6.0 GPM for the HT50KX proportional. The crane's relief pressure is set at 3000 psi.
-
Page 14: 22345A
The boom angle is shown by a gravity arrow. SNATCH BLOCK If the load exceeds 3000 lbs.-HT40KX or 4000 lbs.-HT50KX or if reduced winching speed for better control of smaller loads is required, use the snatch block to rig the crane for two part line operation. -
Page 15: 22345B
2. The center of the crane should be positioned close enough to the job so that it can be operated at a reach that puts the load within the rated capacity of the crane. SECTION TITLE DATE INSTALLATION DWG 3-4-03E C200 MFG., INC. 22345b SUPERCEDES CINCINNATI, OHIO HT40KX, HT50KX 11-3-00D... -
Page 16: 22345C
The lower quill bearing is self lubricating. Remove rear cover and check all hydraulic tube and hose fittings for tightness. Check electrical connections for looseness and corrosion. SECTION TITLE DATE INSTALLATION DWG 3-12-03C C200 MFG., INC. 22345c SUPERCEDES CINCINNATI, OHIO HT40KX, HT50KX 8-12-99B... - Page 17 BU – Boom Up (Elev.) MANUAL OVERRIDE SYSTEM Should an electrical failure occur, your Venturo crane can be operated manually. The manual overrides are intended for emergency use only and should not be used for normal operation. To operate in manual override mode: (1) Override the safety shutoff or proportional valve by turning the red stem on the valve as stated below.
-
Page 21: Wire Rope Installation
THE WINCH BRAKE VALVE WILL NOT HOLD THE LOAD. NOTE: ON THE ET25K(X) A 7/16" HEX NUT WILL BE USED IN LIEU OF A WEDGE. DATE SECTION TITLE 11-22-02D WIRE ROPE INSTALLATION DRAWING C200 MANUFACTURING, INC. SUPERCEDES 22245 CINCINNATI, OHIO ET/HT25K(X),HT40KX, HT50KX 4-19-02C... -
Page 22: Section 300
SECTION 300 MAINTENANCE & SERVICE 7607300A... - Page 23 DATE SECTION TITLE 1-19-00D ASSEMBLY & SERVICE INST. C320 MANUFACTURING, INC. SUPERCEDES CINCINNATI, OHIO 14544 8-10-98C ET 20,000, ET20K(X), ET25K(X), HT25K(X), HT40/50KX...
- Page 24 DATE SECTION TITLE 8-10-98B ASSEMBLY & SERVICE INST. C320 MANUFACTURING, INC. SUPERCEDES CINCINNATI, OHIO 14553 3-10-82A ET 20,000 CRANE...
-
Page 25: Section 400
SECTION 400 PARTS 7607400A... -
Page 26: Replacement Parts
REPLACEMENT PARTS LIST - REF 22517 REPLACEMENT PARTS LIST - FULL POWER BOOM 22572 REPLACEMENT FASTENERS LIST REF 22518 28 29 TITLE SECTION DATE REPLACEMENT PARTS C400 1-19-04D MANUFACTURING, INC. SUPERSEDES CINCINNATI, OHIO HT40KX, HT50KX 3-4-03C... - Page 27 BOOM ASSEMBLY - HT40/50KX 24550 FULL POWER BOOM ASSEMBLY - HT40/50KXX 22266 WINCH - 3000 LB (SINGLE LINE) - HT40KX 22268 WINCH - 4000 LB (SINGLE LINE) - HT50KX 22274 PIVOT PIN, CYL TAIL - 1-1/2" OD x 2-13/16" LONG 22275 PIVOT PIN, CYL ROD - 1-1/2"...
- Page 28 PHCS - 3/8"-16 x 1/2" COUPLING FOR MASTER BYPASS VALVE REPLACEMENT PARTS DWG REF 22346 SERIAL NO. 84030 & UP SERIAL NO. 85030 & UP DATE SECTION TITLE REPL. FASTENERS LIST 7-17-00B C400 MFG., INC. SUPERCEDES 22518 CINCINNATI, OHIO HT40KX, HT50KX 6-8-98A...
- Page 30 18957 BEARING PAD - SIDE FRONT 24568 PIN - CYLINDER 24566 * EXTENSION CYLINDER 24558 PIN BLOCK 22032-2 * EXTENSION CYLINDER 24556-2 TERTIARY BOOM TUBE ASSEMBLY !CACS06318100 COUNTERSUNK ALLEN HEAD CAP SCREW 5/8-18 X 1" LONG 24556-1 TERTIARY BOOM TUBE ASSEMBLY !LOWSH-050 LOCK WASHER - 1/2-13 !HNUT-03816...
- Page 31 REPLACEMENT PARTS LIST REF 22361 24 25 ROTATION RIGHT ROTATION LEFT PRESSURE BOOM OUT RETURN BOOM IN BOOM UP BOOM DOWN PRESSURE RETURN WINCH UP LEFT SIDE VIEW REAR VIEW RIGHT SIDE VIEW WINCH DOWN REPLACEMENT PARTS DRAWING 10-10-02 C400 20699 HT40/50KX HYDRAULIC COMPONENTS...
- Page 32 ITEM PART NUMBER DESCRIPTION 20685 PRESSURE HOSE - HOUSING SIDE 20686 RETURN HOSE - HOUSING SIDE 22501 VALVE BANK - HT40KX, HT50KX 22523 VALVE ASSEMBLY (VALVE BLOCK, VALVE, COIL, & HARDWARE) 22362 COIL ONLY 22363 EXTENSION CYLINDER HOSE 22505 HYD TUBING - ROTATION RIGHT...
- Page 36 22460 PENDANT (PROP W/OUT ENG CTRLS) 19427 (MALE) YEL & YEL/BLK & ORN - GROUND PUR/BLK - WD PUR - WU RED/BLK - RR RED - RL GRN/BLK - BD GRN - BU ORN/BLK - BI BLK - BO BLU - 12V+ BLU/BLK - TRIGGER PLUG - BACKSIDE VIEW PENDANT HEAD - BACKSIDE VIEW...
- Page 37 STRAIN RELIEF - STRAIGHT (1/2" PIPE) 22454 CABLE GUIDE - BLACK DELRIN CABLE 22456 CONNECTOR / SET-COLLAR ASSEMBLY DETAIL VIEW - A 22453 MICROSWITCH 19377-3 WEIGHT ASSY. ITEM PART NO. DESCRIPTION TITLE DATE SECTION 5-21-04D C400 MANUFACTURING, INC. SUPERSEDES 22449 CINCINNATI, OHIO HT40KX, HT50KX 7-3-03C...
- Page 38 !HNUT#1024 NOTE: FOR STANDARD LEFT HAND CORD REEL !LWSH-#10-STAR2 20951-3 HANGER CABLE 22683 CORD REEL ASSEMBLY - LEFT HAND !LNUT-02520 LOCK NUT, NYLON 1/4-20 !FWSH-025 FLAT WASHER 1/4 !HHCS02520275 HHCS 1/4-20 x 2-3/4" GR. 5 PL-20-469 LOCKNUT (1/2" PIPE) 19060 STRAIN RELIEF - 90DEG !PHCS#1024050 !LWSH-#10-STAR2...
-
Page 39: 19294 Pto Package
19294 PTO PACKAGES PUMP MOUNTING RECOMMENDED GPM (RPM) HT18 - STD. - 1.75 GPM (1110 RPM) 19296-1.60 SAE "A" HT25 - STD. - 2.00 GPM (1250 RPM) 9 TOOTH HT40 - STD. - 2.6 GPM (1000 RPM) 19296-2.64 SPLINED SHAFT HT50 - STD.
