Summary of Contents for Venturo HT50KX
- Page 3 TABLE OF CONTENTS HT50KX / Prop Ctrl / W/ Eng Ctrls (HS*AAD-PB**) SECTION 100 DESCRIPTION & SPECIFICATIONS 22912 INSTALLATION DIMENSIONS 18353 MOUNTING DIMENSIONS - BASE PLATE 22351 CAPACITY CHART - HT50KX SECTION 150 SAFETY 15394 VEHICLE & CRANE ELECTRICAL HAZARD INFORMATION 920612 SAFETY &...
- Page 5 SECTION 100 DESCRIPTION & SPECIFICATIONS 7607100A...
- Page 9 SECTION 150 SAFETY 8604150...
- Page 10 VEHICLE & CRANE MOUNTED ELECTRICAL HAZARD SIGN APPLICATION & INFORMATION ET & HT CRANE SERIES SIGN NO. 15393A DISPLAYS THE INTERNATIONAL SYMBOL FOR ELECTRICITY AND WARNS OF DANGER FROM AN ELECTRICALLY CHARGED VEHICLE, CRANE, OR LOAD. FOUR ARE RECOMMENDED (ONE FOR EACH SIDE AND ONE FOR EACH END OF VEHICLE) TO BE APPLIED IN LOCATIONS WHICH ARE READILY VISIBLE TO GROUND PERSONNEL.
- Page 11 CRANE SAFETY AND HAZARDS HT25KX, HT40KX, HT50KX CAUTIONS 1. INSPECT VEHICLE AND CRANE, INCLUDING OPERATION, PRIOR TO USE DAILY. 2. DO NOT USE THIS EQUIPMENT EXCEPT ON SOLID, LEVEL SURFACE WITH CRANE MOUNTED ON FACTORY-RECOMMENDED TRUCK. 3. BEFORE OPERATING THE CRANE, REFER TO MAXIMUM LOAD (CAPACITY) CHART ON CRANE FOR OPERATING (LOAD) LIMITATIONS.
- Page 12 WINCH SAFETY WARNINGS DATE SECTION TITLE INSTALLATION DWG 5-26-98B C150 MFG., INC. SUPERCEDES I19217 CINCINNATI, OHIO HT CRANES 10-17-97A...
- Page 18 SECTION 200 INSTALLATION 7607200A...
- Page 19 The maximum combined overturning moment for the HT40KX is 45,000 ft. lbs. and for the HT50KX is 55,000 ft. lbs. The maximum vertical load for the HT40KX is 7100 lbs. and for the HT50KX is 9300 lbs. CRANE MOUNTING The crane base plate or mounting pedestal must be bolted to the body reinforcing plate with eight (8) grade five (5) bolts of 1"...
- Page 20 The PTO pump should be sized to allow an engine idle speed range that will deliver approxi- mately 2.5 GPM for the HT40KX standard (non-proportional), 12.0 GPM for the HT40KX proportional, 3.0 GPM for the HT50KX standard or 12.0 GPM for the HT50KX proportional. The crane's relief pressure is set at 3000 psi.
- Page 21 The boom angle is shown by a gravity arrow. SNATCH BLOCK If the load exceeds 3000 lbs.-HT40KX or 4000 lbs.-HT50KX or if reduced winching speed for better control of smaller loads is required, use the snatch block to rig the crane for two part line operation.
- Page 22 2. The center of the crane should be positioned close enough to the job so that it can be operated at a reach that puts the load within the rated capacity of the crane. DATE SECTION TITLE INSTALLATION DWG 11-4-08F C200 MFG., INC. SUPERCEDES 22345b CINCINNATI, OHIO HT40KX, HT50KX 3-4-03E...
- Page 23 Bottom of Swing Bearing (2 fittings) Remove rear cover and check all hydraulic tube and hose fittings for tightness. Check electrical connections for looseness and corrosion. DATE SECTION TITLE INSTALLATION DWG 2-3-09A C200 MFG., INC. SUPERCEDES 22174 CINCINNATI, OHIO 5-13-05 HT40KX, HT50KX, HT66KX...
- Page 24 BU – Boom Up (Elev.) MANUAL OVERRIDE SYSTEM Should an electrical failure occur, your Venturo crane can be operated manually. The manual overrides are intended for emergency use only and should not be used for normal operation. To operate in manual override mode: (1) Override the proportional valve by turning the red stem on the valve as stated below.
- Page 30 SECTION 400 PARTS 7607400A...
- Page 39 HYDRAULIC SYSTEM COMPONENTS - HT40/50KX CRANES REPLACEMENT PARTS LIST ITEM PART NUMBER DESCRIPTION 22760 HOSE ASSY. - PRESSURE (SOURCE TO BULKHEAD) 22761 HOSE ASSY. - RETURN (BULKHEAD TO RESERVOIR) 27592 HOSE ASSY. BOOM IN / OUT 27598 HOSE ASSY. - ROTATION FF6400-0606 ADAPTER - 6OFS - 6MO (VALVE BLOCK: ROTATION LT / RT) FF6801-0606...
- Page 49 OIL DECAL 14473-2 GREASE DECAL 22496 VENTURO DECAL (LARGE) 15401 UNLAWFUL TO OPERATE DECAL 22352-1 HT50KX BOOM CAPACITY DECAL (RIGHT) 22352-2 HT50KX BOOM CAPACITY DECAL (LEFT) 19747 HT50KX DECAL 15392 DANGER ELECTROCUTION HAZZARD DECAL 15391 CRANE NOT PASSENGER LIFT DECAL...
- Page 52 LIMITED WARRANTY POLICY This limited policy warrants new products of Venturo be free from defects in material and workmanship for a period of one (1) year from date of original installation. This warranty covers: ♦ Repair or replacement of product ♦...
