Ordering information

Versions that mutually exclude one another are not marked.
010 Approval:
AA Non-hazardous area
BB ATEX II 1/2G Ex ia IIC T5
CA CSA C/US General Purpose
CB CSA C/US IS CI.I Div.1 Gr.A-D
IB IEC Ex zone 0/1, Ex ia IIC T5 Ga/Gb
NB NEPSI zone 0/1, Ex ia IIC T5 Ga/Gb
99 Special version
020 Display; Operating:
G W/o; via spare part display FMU30
H Envelope curve display on site; push button
Y Special version
030 Electrical Connection:
E Gland M20, IP68
F Thread G1/2, IP68
G Thread NPT1/2, IP68
Y Special version
040 Sensor; Max Range; Blocking Distance:
AA 1-1/2"; 5m liquid/2m solid; 0.25m
AB 2"; 8m liquid/3.5m solid; 0.35m
YY Special version
050 Process Connection:
GGF Thread ISO228 G1-1/2, PP
GHF Thread ISO228 G2, PP
RGF Thread ANSI MNPT1-1/2, PP
RHF Thread ANSI MNPT2, PP
YYY Special version
620 Accessory Enclosed:
RA UNI flange 2"/DN50/50, PP max 4bar abs/58psia, suitable for 2" 150lbs/DN50 PN16/10K 50
RB UNI flange 2"/DN50/50, PVDF max 4bar abs/58psia, suitable for 2" 150lbs/DN50 PN16/10K 50
RC UNI flange 2"/DN50/50, 316L max 4bar abs/58psia, suitable for 2" 150lbs/DN50 PN16/10K 50
RD UNI flange 3"/DN80/80, PP max 4bar abs/58psia, suitable for 3" 150lbs/DN80 PN16/10K 80
RE UNI flange 3"/DN80/80, PVDF max 4bar abs/58psia, suitable for 3" 150lbs/DN80 PN16/10K 80
RF UNI flange 3"/DN80/80, 316L max 4bar abs/58psia, suitable for 3" 150lbs/DN80 PN16/10K 80
RG UNI flange 4"/DN100/100, PP max 4bar abs/58psia, suitable for 4" 150lbs/DN100 PN16/10K 100
RH UNI flange 4"/DN100/100, PVDF max 4bar abs/58psia, suitable for 4" 150lbs/DN100 PN16/10K 100
RI UNI flange 4"/DN100/100, 316L max 4bar abs/58psia, suitable for 4" 150lbs/DN100 PN16/10K 100
R9 Special version
895 Marking:
Z1 Tagging (TAG), see additional spec.
You can enter the versions for the specific feature in the following table. The versions entered make up the
complete order code. Options which are mutually exclucive are not marked.
010 020
FMU30 -
Endress+Hauser supplies DIN/EN flanges made of stainless steel AISI 316L with the material number 1.4404
or 1.4435. With regard to their temperature stability properties, the materials 1.4404 and 1.4435 are grouped
under 13E0 in EN 1092-1 Tab. 18. The chemical composition of the two materials can be identical.
030 040 050 620 895
