Prosonic T FMU30
Materials
Endress+Hauser
Заказывайте на сайте: www.tinnova.ru/endress_hauser/ || Эл. почта: info@tinnova.ru
13
12
11
10
9
8
7
6
Pos. Part
Cover (grey)
1
Cover (transparent)
O-ring
2
Ground terminal:
Screws
Spring washer
Clamp
Holder
3
Nameplate
4
O-ring
5
Sensor (in contact with process)
6
Matching Layer (in contact with process)
7
Counter nut (in contact with process)
8
Sealing (in contact with process)
9
Sealing
10
Adapter of housing
11
Goretex filter
Cable gland
12
Plug
13
Housing
Note!
The chemical compatibility of the sensors must be checked before installation with compatibility charts.
1
2
3
4
5
Material
PBT
PA
EPDM
A2
A4
304 (1.4301)
301 (1.4310)
Polyester
EPDM
PP
EPDM
PC
EPDM
EPDM
PBT GF 30-FR
PBT-20GF / grey RAL7035
Polyamid (PA)
PBT-GF30
PBT-FR
L00-FMU3xxxx-16-00-00-xx-001
15
