Prosonic T FMU30
Installation conditions for flow
measurements
Endress+Hauser
Заказывайте на сайте: www.tinnova.ru/endress_hauser/ || Эл. почта: info@tinnova.ru
• Install the instrument at the inflow side (B), as close above the maximum water level H
into account the blocking distance BD).
• Position the instrument in the middle of the channel or weir.
• Align the sensor membrane parallel to the water surface.
• Keep to the installation distance of the channel or weir.
Example: Khafagi-Venturi flume
A
A
Khafagi-Venturi flume
B
Inflow
C
Outflow
Example: Triangular weir
min. 2 H
BD
E
BD Blocking distance
E Empty calibration
F Full calibration
B
BD
E
H
=F
V
max
1 x b
0
b
0
BD
Blocking distance
E
Empty calibration
F
Full calibration
V
Direction of flow
max.
a
min. 3 H
max.
as possible (take
max
C
A0019607
H
(= F)
max.
min. 2 H
max.
L00-FMU30xxx-17-00-00-xx-012
11
