Commissioning
Parameter
Installationйdirection
Parameter
Assignйprocessйvariable
Unitйtotalizer
Totalizerйoperationйmode
Failureйmode
90
10.5.2 Carrying out a sensor adjustment
TheйSensor adjustmentйsubmenuйcontainsйparametersйthatйpertainйtoйtheйfunctionalityйof
theйsensor.
Navigation
"Setup"йmenuй йAdvancedйsetupй йSensorйadjustment
Structure of the submenu
Sensor adjustment
Parameter overview with brief description
Description
Setйsignйofйflowйdirectionйtoйmatchйthe
directionйofйtheйarrowйonйtheйsensor.
10.5.3 Configuring the totalizer
Inйtheй"Totalizer 1 to 3" submenuйtheйindividualйtotalizersйcanйbeйconfigured.
Navigation
"Setup"йmenuй йAdvancedйsetupй йTotalizerй1йtoй3
Totalizer 1 to 3
Parameter overview with brief description
Description
Selectйprocessйvariableйforйtotalizer.
Selectйprocessйvariableйtotalizerйunit.
Selectйtotalizerйcalculationйmode.
Defineйtotalizerйbehaviorйinйalarmйcondition.
ProlineйPromagйDй400йHART
Installationйdirection
Selection
• Flowйinйarrowйdirection
• Flowйagainstйarrowйdirection
Assignйprocessйvariable
Unitйtotalizer
Totalizerйoperationйmode
Failureйmode
Selection
• Off
• Volumeйflow
• Massйflow
Unitйchooseйlist
• Netйflowйtotal
• Forwardйflowйtotal
• Reverseйflowйtotal
• Stop
• Actualйvalue
• Lastйvalidйvalue
Factory setting
Flowйinйarrowйdirection
Factory setting
Volumeйflow
l
Netйflowйtotal
Stop
