Step 8 Z - Axis Assembly
Step 1: Prepare the Z Axis Carriage and Leadscrew.
Compress the Anti-Backlash Spring into the Hole shown below.
Use the Copper Nut to slide into the spring and hold it into place.
While compressed, thread the Leadscrew through the assembly.
