X-Z Axis Assembly Installation - Genmitsu 3018-PRO User Manual

Step 6 X-Z Axis Assembly Installation
What you will need
(2) Aluminum Profile
2
20 x 20 x 360mm
12 (2) Stepper motor
34 Copper Nut
16
(2) Guide Rail
4
X Axis, Ø10 x 360mm
14 X-Z Axis Assembly
Anti-Backlash Spring
37
Lead Screw 365mm
6
32 (4) Bolt M5 x 16
Coupling & Set Screw
38
33 (4) Bolt M3 x 14
