Command
0x78 0x00 Timer1Data
0x78 0x04 LTCUserBitsTimeData
0x78 0x06 VITCUserBitsTimeData
0x74 0x06 VITCTimeData
0x74 0x07 UserBitsVITCTimeData
0x74 0x08 GenTCData
0x78 0x08 GenTCUBData
0x74 0x09 GenUBData
0x74 0x10 InData
0x74 0x11 OutData
0x74 0x12 AInData
0x74 0x13 AOutData
0x74 0x14 CorrectedLTCTimeData
0x70 0x20 StatusData
0x76 0x2B RemainTimeData
0x71 0x2E SpeedData
0x74 0x31 PrerollTimeData
0x71 0x36 TimerModeData
0x72 0x3E RecordInhibitStatus
A - Advanced Media Protocol
0xA1 0x01 AutoSkip
0xAX 0x15 ListNextID
0x20 0x29 ClearPlaylist
0x41 0x42 SetPlaybackLoop
0x41 0x44 SetStopMode
Reply No Remote
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
Acknowledge Disabled
IDListing Enabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Notes
Current Time and
00:00:00:00
Current Time and
00:00:00:00
Current Time and
00:00:00:00
Current Time
00:00:00:00
Current Time
Current Time and
00:00:00:00
00:00:00:00
Current Time
Please see "Status Bits"
sheet: Limited to 9 bytes
of status, silently
truncated
Returns 0 (TimeCode)
8-bit signed number of
clips to skip from current
clip
when x = 0 single clip
request when x = 1, #
clips can be specified in
the send data
Bit 0 loop mode enable,
0=false 1=true
Bit 1 is single clip/timeline
0=single clip
1=timeline
0 = Off
1 = Freeze on last frame
2 = Freeze on next clip
3 = Show black
