Command
0x20 0x61 FullEEOn
0x20 0x63 SelectEEOn
4 - Preset/Select Control
0x40 0x10 InEntry
0x22 0x23 ShuttleRev2
0x20 0x30 Preroll
0x24 0x31 CueData
0x20 0x34 SyncPlay
0x21 0x38 ProgSpeedPlayPlus
0x21 0x39 ProgSpeedPlayMinus
0x40 0x11 OutEntry
0x44 0x14 InDataPreset
0x44 0x15 OutDataPreset
0x40 0x18 InShift+
0x40 0x19 InShift-
0x40 0x1A OutShift+
0x40 0x1B OutShift-
0x40 0x20 InReset
0x40 0x21 OutReset
0x40 0x22 AInReset
0x40 0x23 AOutReset
0x44 0x31 PrerollPreset
0x40 0x40 AutoModeOff
0x40 0x41 AutoModeOn
0x41 0x37 InputCheck
6 - Sense Request
0x61 0x0A TimeCodeGenSense
0x61 0x0C CurrentTimeSense
0x60 0x10 InDataSense
0x60 0x11 OutDataSense
0x60 0x12 AInDataSense
0x60 0x13 AOutDataSense
0x61 0x20 StatusSense
0x60 0x2B RemainTimeSense
0x60 0x2E SpeedSense
0x60 0x31 PrerollTimeSense
0x60 0x36 TimerModeSense
0x60 0x3E RecordInhibitSense
7 - Sense Reply
Reply No Remote
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
Acknowledge Disabled
— —
— —
InData Enabled
OutData Enabled
AInData Enabled
AOutData Enabled
StatusData Enabled
RemainTimeData Enabled
SpeedData Enabled
PreRollTimeData Enabled
TimerModeData Enabled
RecordInhibitStatus Enabled
Notes
Treated as N=1;
Same as ShuttleRev1
ignored, Status bit
remembered
ignored, Status bit
remembered
RS-422 Control 32
