10. APPENDIX
10.1. FIGURES AND TABLES
If UPS alarms and buzzer sound, press "FUNC" key to get alarm code on the fault menu. To clear fault press
Code Cause
7 No Battery
8 Manual Bypass ON
EPO
10
16 Utility Abnormal
Bypass Abnormal
20
Bypass Faulty
22
Bypass Overload
24
Bypass Overload Timeout
26
Over Synchronization
28
Over Transfer Times
30
Output Shorted
32
Rectifier Fault
47
Inverter Fault
49
Rectifier Over Temperature
51
Troubleshooting
and hold "FUNC" key for 2.5s at fault menu
Solutions
• Check if battery cables are connected properly
• Check if battery breaker or fused are open
• Check if batteries are damaged
Manual bypass housing open, UPS will transfer will transfer to static bypass
and will impede inverter operation mode.
• Check if EPO is closed correctly
• Check if EPO is activated manually
UPS mains input is abnormal.
•
Check if mains input is normal
•
Check if mains input voltage and frequency is over the working range
• Check if mains input breaker or external input breaker is opened
Please recover mains input power, otherwise output will be shutdown if bat-
tery is discharged to EOD.
Check if bypass input power is abnormal
Check if bypass input breaker is opened
Bypass SCR is opened or shorted, please contact DSPM.
Check the load and remove some non critical load until the load is be-
•
low 95%
Bypass overload and timeout, UPS will shutdown output.
Bypass voltage or frequency is over tracking range. There could be in-
terruption if manually transferred to bypass or inverter faults.
Main, battery, inverter, or bypass transfer occur 5 times in 1 Hour.
Load is abnormal or output breaker is shorted.
Check load for short and eliminate if any
•
Check output breaker for short
•
After verifying no short is present at output, restart UPS.
DC BUS over/under voltage, or shorted/opened IGBT. Restart UPS, if
issue still persist contact DSPM.
Inverter voltage is abnormal, or inverter IGBT is shorted/opened. Re-
start UPS, if issue still persist contact DSPM.
Rectifier heatsink is reading above maximum threshold.
Check if fans are working properly
•
Check if anything blocking ventilation
•
Check if the temperature sensor is connected correctly
•
Check if the environmental temp is over the range of UPS
•
