5.4. INPUT AND OUTPUT POWER REQUIREMENTS / CONNECTIONS
5.5. SYSTEM CURRENT RATINGS
All circuit breakers provided by the end user that are connected to the inputs and outputs, need to be of
the "High Inrush" type. This is to prevent the breakers from tripping during the startup of the unit and its
load. DSPM uses only the "High Inrush" type of breaker in its units. Refer to Figure 8 when determining
the size of your input and output breakers.
5.6. GROUNDING
Title: Plus/PCL
Doc No.: 018-2000-AEC
Description: Emergency Lighting Inverter User's Manual
Rev: NR
Page#: - 28 -
Date: 08/28/2020
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
