INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the Parts
List in the appropriate place in your machine manual for future reference.
Retaining the Parts List will make it easier to reorder individual parts and will
save you the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Installation instructions for kit number 374132
SYNOPSIS / PROBLEM:
This kit contains the parts needed to replace the solution control system on the model 5700
scrubber.
Please follow step-by-step instructions.
SPECIAL TOOLS / CONSIDERATIONS: NONE
(Estimated time to complete: 1 hour)

PREPARATION:

(Refer to FIG. 1 thru 4)
1. Empty the machine solution tank.
2. Move the machine to a clean level surface.
FOR SAFETY: Before leaving or servicing machine, stop on level surface and set parking
brake. Then turn off machine and remove key.
3. Remove front cover from machine. Set the front cover and mounting hardware aside.
4. Locate the solution control group mounted underneath the front of the solution tank.
5. Raise the solution tank and engage the solution tank support arm.

INSTALLATION:

(Refer to FIG. 1 thru 4)
1. Disconnect and remove the front PVC hose from the solenoid valve and T--fitting mounted
to the top of the scrub head.
2. Disconnect push/pull cable from the pinch lever on the valve mounting bracket.
3. Remove and set aside the pinch lever from the valve mounting bracket.
4. Remove and discard the straight hose connecting solution tank to solution control valve.
5. Remove and discard the old solenoid valve.
6. Remove the old valve mounting bracket from the machine. Set the mounting hardware
aside.
(Refer to FIG. 1)
IB 340513 (10-01)
(Refer to FIG. 1)
(Refer to FIG. 1)
No. 340513
Machine: 5700
Published: 10-01/00
System: SCRUBBING
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 340513 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tennant 340513

  • Page 1 4. Remove and discard the straight hose connecting solution tank to solution control valve. 5. Remove and discard the old solenoid valve. (Refer to FIG. 1) 6. Remove the old valve mounting bracket from the machine. Set the mounting hardware aside. (Refer to FIG. 1) IB 340513 (10-01)
  • Page 2 BILL OF MATERIALS FOR SOLUTION VALVE REPLACEMENT KIT 374754 TENNANT Ref. Part No. Description Qty. 397787 Bracket, mtg, valve 374752 Valve, solenoid 397777 Hose, rbr, E90, 0.62ID 0.81ID (valve) 374753 Hose, PVC TENNANT COMPANY P. O. Box 1452 Minneapolis, MN 55440-1452 IB 340513 (10-01)
  • Page 3 Remove pinch lever from old bracket Disconnect cable from pinch lever Disconnect and remove old solenoid valve, straight hose, and mounting bracket FIG. 1 - - Old Solution Control Group, 5700 IB 340513 (10-01)
  • Page 4 Mount set aside pinch lever to new mounting bracket Reconnect cable to pinch lever FIG. 2 - - New Solution Control Group, 5700 IB 340513 (10-01)
  • Page 5 53/GRN 62A/ 54/BRN 13V/ 13R/BLK LOWER 64A/ TANK (ES) 13U/ LEVEL SWITCH ES PUMP PROPEL 13S/ MOTOR BATTERIES 13DD 1/RED 71C/ 71B/ 13Y/ 13X/ 2/RED VAC FAN MAIN HARNESS FIG. 3 - - Wire Harness Group, 5700 IB 340513 (10-01)
  • Page 6 FIG. 4 - - Electrical Schematic, 5700 IB 340513 (10-01)
