- Page 1 No: 89 71 36 Revision 1 2007.11 Installation, care and maintenance www.grindex.com MICRO MACRO SOLID...
-
Page 2: Table Of Contents
Installation, care and maintenance Micro, Macro, Solid Contents Product description __________________3 Operation ___________________________8 Applications ______________________________ 3 Care and maintenance ________________9 Motor data ________________________________ 3 Inspection ________________________________ 9 Technical data _____________________________ 3 Tightening & lubricating screws ______________ 9 Dimensions _______________________________ 3... -
Page 3: Product Description
Installation, care and maintenance Micro, Macro, Solid Product description Applications Technical data Micro and Macro pumps are intended to be used for Liquid temperature 5 - 35°C (41 - 95°F) pumping water which may contain abrasive particles. The pH of the pumped... -
Page 4: Performance Curves
Installation, care and maintenance Micro, Macro, Solid Performance curves Each pump is tested in accordance with ISO 9906. Micro, Macro, Solid 50 Hz Micro, Macro, Solid 60 Hz [hp] / [KW] [hp] / [KW] Solid Solid Macro Macro Micro Micro... -
Page 5: Installation
Installation, care and maintenance Micro, Macro, Solid Installation Pump installation NOTE! Run the cables so that they do not have any sharp Where required by local authori- bends and are not pinched. ties an acceptable motor-circuit Connect the discharge connection and motor cable. -
Page 6: Electrical Connections
Installation, care and maintenance Micro, Macro, Solid Electrical connections Level regulators WARNING! Start and stop of the pump at different water levels may All electrical equipment must be manual or automatic. If automatic start and stop is be earthed (grounded). This ap- required, a level regulator can be ordered (as option). -
Page 7: Wiring Diagram
Installation, care and maintenance Micro, Macro, Solid Wiring diagram Blue Plug Black Brown Brown contact Green/Yellow White White White = Connector Capacitor Stator Alternative with Level regulator Green/Yellow To level Brown regulator Blue Brown Blue Plug Black Brown Brown contact... -
Page 8: Operation
Installation, care and maintenance Micro, Macro, Solid Operation Before starting Cleaning Check the oil level in the oil casing. If the pump has been running in very dirty water, let it run for a while in clean water, or flush it through the Remove the fuses or open the circuit breaker and check discharge connection. -
Page 9: Care And Maintenance
Installation, care and maintenance Micro, Macro, Solid Care and maintenance Inspection Lubricating screws Regular inspection and preventive maintenance ensure To maintain screw tightness use a little mineral oil on all more reliable operation. non-stainless screws (not synthetic lubricants!). The pump should be inspected at least twice a year, more frequently under severe operating conditions. -
Page 10: Spare Parts Kits
Spare parts Spare part kits Spare parts for the Micro, Macro and Solid pumps are available in handy kits to make service and repair work easier. Each kit contains an instruction sheet together with the replacement parts. When ordering please refer to the kit part numbers listed below:... -
Page 11: Main Parts
Installation, care and maintenance Micro, Macro, Solid Main parts Micro and Macro Item Denomination Cable Plug contact Handle/cover Support bearing Pump casing Main bearing Inner mechanical seal Oil plug Outer mechanical seal Diffuser Discharge connection Motor Impeller Strainer Solid Item... - Page 12 Grindex AB Hantverkarvägen 24, Box 538, 136 25 Haninge, Sweden Tel: +46 8 606 66 00 Fax: +46 8 745 53 28 marketing@grindex.com www.grindex.com • • • • •...
