Nurse Call Cables/Leads

Leads available from Alert-iT

Our wide selection of nurse call leads has grown over many years so it is very likely that we will already have a
suitable lead available to connect the Nurse Call Receiver to your nurse call system.
Please browse our website or contact our sales team to help you find the correct lead;
Call:
+44 (0) 1530 239 900
Email: sales@alert-it.co.uk
Visit: www.alert-it.co.uk/product-category/accessories/
If we don't currently have one suitable for you, please send us your connection details and we will add it to our
catalogue for you.

Wired Output Specification

If you wish to make your own lead, the connection into the Connect-iT can be wired as follows:
Connector: RJ11 / RJ12 (Gold contacts visible on top, clip underneath)
1
PIN 1
Normally Closed
PIN 2
12V Out
PIN 3
Normally Open
PIN 4
Common
PIN 5
0v
PIN 6
No Connection
6
