Summary of Contents for GMI PSD1001
- Page 1 PSD1001 INSTRUCTION MANUAL SIL 3 - SIL 2 Quad channel Power Supply for Hazardous Area Equipment DIN-Rail Model PSD1001 PSD1001 - SIL 3 - SIL 2 Quad ch. Power Supply for Hazardous Area Equipment ISM0023-11...
-
Page 2: Technical Data
Characteristics General Description: The PSD1001 is a quad channel DIN Rail Power Supply to drive measuring, process control equipments in Hazardous Area; it provides isolation between input and output. Typical application is to drive 4-20 mA 2 wires transmitter with local indication (current is not repeated in Safe Area). -
Page 3: Terminal Block Connections
+ Output Ch 2 for 2 wire Device - Output Ch 2 for Solenoid Valve or - Output Ch 2 for 2 wire Device G.M. International ISM0023-11 PSD1001 - SIL 3 - SIL 2 Quad ch. Power Supply for Hazardous Area Equipment... - Page 4 Hazardous Area/Hazardous Locations and gas group encountered and that its maximum allowable voltage, current, power (Ui/Vmax, Ii/Imax, Pi/Pi) are not exceeded by the safety parameters (Uo/Voc, Io/Isc, Po/Po) of the PSD1001 Associated Apparatus connected to it. Also consider the maximum operating temperature of the field device, check that added connecting cable and field device capacitance and inductance do not exceed the limits (Co/Ca, Lo/La, Lo/Ro) given in the Associated Apparatus parameters for the effective gas group.
- Page 5 Division 2 installations, the configuration of Intrinsically Safe Equipment must be FM approved under non-incendive field wiring or Entity Concept (or third party approved). G.M. International ISM0023-11 PSD1001 - SIL 3 - SIL 2 Quad ch. Power Supply for Hazardous Area Equipment...
-
Page 6: Function Diagram
MODEL PSD1001 2 wire Solenoid Common positive Device Valve connection 4 - Supply 24 Vdc Out 1 Out 2 Out 3 Out 4 PSD1001 - SIL 3 - SIL 2 Quad ch. Power Supply for Hazardous Area Equipment G.M. International ISM0023-11... -
Page 7: Operation
Non-incendive field wiring is not recognized by the Canadian Electrical Code, installation is permitted in the US only. For installation of the unit in a Class I, Division 2 or Class I, Zone 2 location, the wiring between the control equipment and the PSD1001 associated apparatus shall be accomplished via conduit connections or another acceptable Division 2, Zone 2 wiring method according to the NEC and the CEC. -
Page 8: Installation
PSD1001 is a power supply for field devices housed in a plastic enclosure suitable for installation on T35 DIN Rail according to EN50022. PSD1001 unit can be mounted with any orientation over the entire ambient temperature range, see section “Installation in Cabinet” and "Installation of Electronic Equipments in Cabinet"...
