- Page 1 D6011S - D6011D INSTRUCTION MANUAL SIL 3 Repeater Power Supply Hart, DIN-Rail and Termination Board, Models D6011S, D6011D D6011 - SIL 3 Repeater Power Supply G.M. International ISM0211-2...
-
Page 2: Technical Data
Characteristics General Description: The single and dual channel Repeater Power Supply, D6011S and D6011D module is a high integrity analog input interface suitable for applications requiring SIL 3 level (according to IEC 61508:2010 Ed. 2) in safety related systems for high risk industries. Provides a fully floating dc supply for energizing conventional 2 wires 4-20 mA transmitters, and repeats the current in floating circuit to drive a load. -
Page 3: Ordering Information
Ordering Information Power Bus and DIN-Rail accessories: Model: D6011 Connector JDFT049 Cover and fix MCHP196 1 channel Terminal block male MOR017 Terminal block female MOR022 2 channels Front Panel and Features SIL 3 according to IEC 61508:2010 Ed. 2 for Tproof = 1 / 10 yrs (≤10% / >10 % of total SIF). ... -
Page 4: Function Diagram
2 Wire Tx Source I In 2 Out 2 (SIL 3) Termination board Power Bus connector MODEL D5011S MODEL D6011S Supply 24 Vdc 2 Wire Tx Source I Out (SIL 3) Termination board Power Bus connector D6011 - SIL 3 Repeater Power Supply... -
Page 5: Operation
On the section “Function Diagram” and enclosure side a block diagram identifies all connections. Identify the number of channels of the specific card (e.g. D6011S is a single channel model and D6011D is a dual channel model), the function and location of each connection terminal using the wiring diagram on the corresponding section, as an example: Connect 24 Vdc power supply positive at terminal “5”...
