14. INDICATOR LIGHT GREEN
This green light, located below the switch is on when the LOCAL condition is selected.
15. CONTROL SWITCH
This is a two (2) position toggle switch and is used to select the pump control location.
Move toggle to LOCAL to enable operation of concrete pump from main stationary panel.
Move toggle to REMOTE for operation using the remote control.
16. INDICATOR LIGHT YELLOW
This yellow light, above the switch is on when the REMOTE condition.
17. VOLUME CONTROL
This control is installed on the main hydraulic pump, just forward of the hydraulic
tank. It is used to adjust volume output of the material cylinders which in turn is
controlled
COUNTERCLOCKWISE will INCREASE volume, turning knob CLOCKWISE will
DECREASE volume.
DO NOT VARY THE PUMP OUTPUT BY VARYING
ENGINE SPEED.
REVISION:02/06/2006
REED ROCK MASTER A30HP
TRAILER CONCRETE PUMP
by
the
output
of
the
hydraulic
pump.
Turning
OPER.
PAGE
07
knob
