Network PanoVu Camera
Quick Start Guide
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PanoVu 6A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION PanoVu 6A Series

Summary of Contents for HIKVISION PanoVu 6A Series

  • Page 1 Network PanoVu Camera Quick Start Guide...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Network PanoVu Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 5 Network PanoVu Camera·Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 6 Network PanoVu Camera·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 7 Network PanoVu Camera·Quick Start Guide ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard.
  • Page 8 Network PanoVu Camera·Quick Start Guide ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam. ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30°C ~+60°C, or -40°C ~ +60°C if the camera model has an “H”...

  • Page 9: Table Of Contents

    Network PanoVu Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............9 2 Installation ................13 2.1 Memory Card Installation ..........13 2.2 Ceiling Mounting ............... 14 2.3 Wall Mounting with Bracket ..........17 2.4 Vertical Pole Mounting ............20 2.5 Surveillance Angle Adjustment.........

  • Page 10: Appearance Description

    Network PanoVu Camera·Quick Start Guide 1 Appearance Description Overview (1) Figure 1-1...
  • Page 11 Network PanoVu Camera·Quick Start Guide Figure 1-2 Overview (2) Figure 1-3 Overview (3)
  • Page 12 Network PanoVu Camera·Quick Start Guide Figure 1-4 Overview (4) Table 1-1 Description of Overview Description Description Open cap button Fixing screw Safety rope Memory card slot and reset button cover Tilt adjusting Lens screw Memory card slot Reset button Decorative cover Pan adjusting screw...
  • Page 13 Network PanoVu Camera·Quick Start Guide Description Description Side outlet Cable gland Junction box cover Junction box Included bracket Alarm input Alarm output RJ45 Ethernet Power cord (36 VDC) interface RS-485 interface Audio input Audio output Fiber optical interface (FC) Table 1-2 Status Indicators Indicator Description...

  • Page 14: Installation

    Network PanoVu Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 36 VDC, please make sure your power supply matches with your camera.

  • Page 15: Ceiling Mounting

    Network PanoVu Camera·Quick Start Guide Figure 2-1 Install Memory Card Ceiling Mounting The camera has a ceiling mounting bracket included in the package. Steps: Select a mounting location. Mark 4 screw holes for expansion bolts. Thread the cables through the bracket. Fix the bracket to the ceiling.
  • Page 16 Network PanoVu Camera·Quick Start Guide Fix the cap to the bracket. Fixing Screw Wrench Figure 2-3 Install Cap Hook the safety rope on the cap to the bracket. Thread the cables through the cap. Fit the cap into the bracket, and slightly rotate the cap. Tighten fixing screws on bracket with hex wrench.
  • Page 17 Network PanoVu Camera·Quick Start Guide Figure 2-5 Route Cables Hook the safety rope on the camera to the cap. Hang the camera to the cap. Thread cables through cable gland and junction box cover. Connect the cables. Screw the cable gland back to junction box cover and screw the junction box cover back to camera.

  • Page 18: Wall Mounting With Bracket

    Network PanoVu Camera·Quick Start Guide × 2 × 4 Figure 2-6 Secure Camera to Cap Install the decorative cover. Decorative Cover Figure 2-7 Install Decorative Cover Adjust surveillance angle. See Section 2.5. Wall Mounting with Bracket Wall mounting bracket is not included in package. You need to buy one if you adopts this mounting style.
  • Page 19 Network PanoVu Camera·Quick Start Guide Select a mounting location. Mark 4 screw holes for expansion bolts. Thread the cables through the bracket. Fix the bracket to the wall. Cables Flat Washer Spring Washer Figure 2-8 Secure Wall Mounting Bracket Note: If you prefer routing cable through side outlet, see Section 2.6.
  • Page 20 Network PanoVu Camera·Quick Start Guide Thread the cables through the cap. Fit the cap into the bracket, and tighten fixing screws on bracket with hex wrench. Unscrew the junction box cover Cable Gland Junction Box Cover Figure 2-10 Unscrew Junction Box Cover Route cables.

  • Page 21: Vertical Pole Mounting

    Network PanoVu Camera·Quick Start Guide Hook the safety rope on the camera to the cap. Hang the camera to the cap. Thread cables through cable gland and junction box cover. Connect the cables. Screw the cable gland back to junction box cover and screw the junction box cover back to camera.
  • Page 22 Network PanoVu Camera·Quick Start Guide Adjusting Knob Clamps Cable Hole Figure 2-13 Vertical Pole Mount Rotate the adjusting knobs counterclockwise to open the clamps. Route cable through cable hole. Attach the vertical pole mount to pole and rotate the adjusting knobs clockwise as tight as possible.

  • Page 23: Surveillance Angle Adjustment

    Network PanoVu Camera·Quick Start Guide Surveillance Angle Adjustment Steps: Pan: -90° to +90° Lock Screw 1 Tilt: -45° to +90° Lock Screw 2 Panning Flat Object Adjustment Lock Figure 2-15 Angle Adjustment Adjust panning position. Loosen lock screw 1. Use a flat object (like a coin) to rotate the panning adjustment lock to “unlock”...

  • Page 24: Cable Routing From Side Outlet

    Network PanoVu Camera·Quick Start Guide Loosen lock screw 2 with hex wrench. Hold the camera to adjust its tilting position from -45° to 90°. Tighten lock screw 2 and install the cover back. Cable Routing from Side Outlet Steps: Unscrew the cable gland on junction box cover. Remove the side outlet cover and screw plug at side of the camera base.
  • Page 25 Network PanoVu Camera·Quick Start Guide Install the side outlet cover back and screw the cable gland to the side outlet. Figure 2-18 Install Cable Gland on Side Outlet Unscrew the junction box cover. Thread the cable through cable gland and connect the connectors Figure 2-19 Route Cables and Connect Connectors Install the junction box cover back and tighten cable gland cap.
  • Page 26 Network PanoVu Camera·Quick Start Guide Cable Gland Figure 2-20 Tighten Cable Gland Cap...

  • Page 27: Setting The Network Camera Over The Lan

    Network PanoVu Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 28: Activating The Camera

    Network PanoVu Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 29: Activation Via Sadp Software

    Network PanoVu Camera·Quick Start Guide Activation Interface(Web) Figure 3-3 Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 30 Network PanoVu Camera·Quick Start Guide activate the camera, please refer to the User Manual of Network Camera for other two activation methods. Steps: 1. Run the SADP software to search the online devices. 2. Check the device status from the device list, and select the inactive device.

  • Page 31: Modifying The Ip Address

    Network PanoVu Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 32 Network PanoVu Camera·Quick Start Guide 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Modify the IP Address Figure 3-5 4. Input the admin password and click Modify to activate your IP address modification.
  • Page 33 Network PanoVu Camera·Quick Start Guide The batch IP address modification is supported by the SADP; please refer to the User Manual of SADP for details.

  • Page 34: Accessing Via Web Browser

    Network PanoVu Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 35 Network PanoVu Camera·Quick Start Guide 4. Click Login. Login Interface Figure 4-1 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
  • Page 36 UD06329B...
