DIAPHRAGM BRAKES
MODELS ''J'' AND ''K''
1
FORM NO. L-20012-M-0814

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIR CHAMP J and is the answer not in the manual?

Questions and answers

Related Manuals for Nexen AIR CHAMP J

Summary of Contents for Nexen AIR CHAMP J

  • Page 1 DIAPHRAGM BRAKES MODELS ''J'' AND ''K'' FORM NO. L-20012-M-0814...
  • Page 2 In accordance with Nexen’s established policy of constant product improvement, the specifications contained in this manual are subject to change without notice. Technical data listed in this manual are based on the latest information available at the time of printing and are also subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents General Specifications -------------------------------------------------------------------------------------------------------------------------- 4 General Safety Precautions ------------------------------------------------------------------------------------------------------------------- 4 Installation: "J" or "K" Diaphragm Brake with Optional Drum ------------------------------------------------------------------------------------ 5 "J" or "K" Diaphragm Brake without Optional Drum ------------------------------------------------------------------------------- 5 "J" or "K" Diaphragm Brake with Optional Self-Centering Bracket ----------------------------------------------------------- 5 Lubrication ----------------------------------------------------------------------------------------------------------------------------------------- 6 Air Connections --------------------------------------------------------------------------------------------------------------------------------- 6 Operation ------------------------------------------------------------------------------------------------------------------------------------------ 7...

  • Page 4: General Specifications

    WARNING Ensure proper guarding of the product is used. Nexen recommends the machine builder design guarding in compliance with OSHA 29 CFR 1910 “Occupational Safety and Health Hazards”. CAUTION This product has possible pinch points.

  • Page 5: Installation

    INSTALLATION ''J'' OR ''K'' DIAPHRAGM BRAKE WITH OPTIONAL DRUM NOTE: Refer to Figure 1. Optional Slide the Optional Drum onto the shaft. Drum Tighten the Set Screw; securing the Optional Drum to the shaft. Screw Position the ''J'' or ''K'' Diaphragm Brake on the Optional Drum, with the Pin passing through the slot in the Fixed Shaft Shoe.

  • Page 6: Lubrication

    NOTE Nexen pneumatically actuated devices require clean, pressure regulated air for maximum performance and life. All seals in Nexen pneumatically operated devices are lubricated for life, and do not require additional lubrication. However, some customers prefer to use an air line lubricator, which injects oil into the pressurized air, forcing an oil mist into the air chamber.

  • Page 7: Operation

    (in hrs) can be found by: Time=Volume/ Celsius (40-220 Degree F). (Power*Wear Rate). WARNING Ensure proper guarding of the product is used. Nexen recommends the machine builder design guarding in compliance with OSHA 29 CFR 1910 “Occupational Safety and Health Hazards”. FORM NO. L-20012-M-0814...

  • Page 8: Troubleshooting

    TROUBLESHOOTING Probable Cause: Problem: Solution Ruptured Diaphragm Replace the Diaphragm Failure to engage Faulty air controls Check the air controls for proper operation Faulty or damaged Compression Spring Failure to disengage Replace the Compression Spring Faulty air controls Check the air controls for proper operation Foreign material on the Option Brake Drum Clean the optional Brake Drum or the shaft "J"...

  • Page 9: Friction Facing Replacement

    FRICTION FACING REPLACEMENT ''J'' DIAPHRAGM BRAKE NOTE: Refer to Figure 5. Remove the first two Hex. Head Jam Nuts (Item 11). Remove the Fixed Shoe Assembly (Item 1). Remove the second two Hex. Head Jam Nuts (Item 11). Remove the Set Screw (Item 12). Remove the Sliding Shoe Assembly (Item 2).

  • Page 10: Diaphragm And Spring Replacement

    DIAPHRAGM AND SPRING REPLACEMENT ''J'' DIAPHRAGM BRAKE NOTE: Refer to Figure 7. Remove the Cap Screws (Item 16) and Hex. Nuts (Item 17). Remove the Top Diaphragm Housing (Item 4). Remove the Jam Nut (Item 10) and Washer (Item 9). Remove the Diaphragm (Item 7), Push Plate (Item 6), and Compression Spring (Item 8).

  • Page 11: Replacement Parts List

    The item numbers identify the product parts on all parts lists, price number, part description, and quantity. Replacement parts are lists, unit assembly drawings, bills of materials, and instruction available through your local Nexen Distributor. manuals. ''J'' DIAPHRAGM BRAKE (See Figure 9)

  • Page 12: Accessories

    ACCESSORIES ''J'' DIAPHRAGM BRAKE (See Figure 11) DESCRIPTION PROD. NO. Drum 2-3/4'' [69.85 mm] no bore 842000 FIGURE 11 Drum 2-3/4'' [69.85 mm] 1'' [25.40 mm] bore 842300 DRUM Self-Centering Bracket 842100 ''K'' DIAPHRAGM BRAKE (See Figure 12) DESCRIPTION PROD. NO. Drum 4'' [101.60 mm] no bore 843600 Drum 4'' [101.60 mm] 1'' [25.40 mm] bore...

  • Page 13: Warranty

    Buyer shall be obligated to pay or which Buyer may incur based upon, related to or arising out of its contracts with its customers or other third parties. In no event shall Nexen be liable for any amount of damages in excess of amounts paid by Buyer for Products or services as to which a breach of contract has been determined to exist.

This manual is also suitable for:

Air champ k
