KIOUR VD1F Quick Start Manual

COOLING – HEATING CONTROLLER Model VD1F
ATTENTION
Read carefully these instructions before installing and using this device and keep them for future reference. Attention to installation and electrical wiring. Use this device
only as described in this document and never use itself as a security device. The device must be disposed of in accordance with local standards for the collection of
electrical and electronic equipment.

DESCRIPTION

VD1F is a temperature controller for cooling – heating applications, as well as, food drying applications (e.g. sausages) and has the following specifications: room temperature
is controlled with NTC/PTC sensor;
defrost; a buzzer in case of an alarm; the device is mounted on a panel hole and it is restrained with plastic side brackets; it
network CAMIN via serial input using an interface with MODBUS protocol.

INDICATIONS AND BUTTONS FUNCTION

For more indications regarding the alarms please see the alarm's table at page 3.
ADJUSTING TEMPERATURE – SET POINT
1. Press to display the first parameter SPo.
2. Press to display its value. With
3. Press to save the new value. The device is working properly with the new adjustment.

INDUSTRIAL FACTORY SETTINGS

1. Press to display SPo. Press 4 times
2. Press to display its value and press
3. Press again to exit the parameter menu. All appropriate factory settings are now stored in the device.

ON/OFF DEVICE

1. To deactivate the device, press at the same time
2. To activate the device, press for 3 seconds

MANUAL DEFROST

Press for 3 seconds to start a manual defrost with duration based on the parameter dd2.
PROGRAMMING A PARAMETER
ATTENTION: to gain full access to the parameter's menu, the 5
1. Press to enter the parameter menu.
2. Choose the parameter you want to adjust by pressing
3. Press or to change its value and then press
4. Press to exit the parameter menu.

TECHNICAL SPECIFICATIONS

Power supply: 230VAC 50/60Hz / Maximum power consumption: 3W / Firmware: V2
It is recommended using a power supply safety fuse: 0.5Α (not included)
Room temperature sensor NTC 10K 1% 25°C ΙΡ68 with temperature range -37÷+110°C (-34÷+230°F) (or PTC 1Κ 25
not included) / Accuracy: ±0.5°C
Alarm buzzer / Serial input with 5pin connector / Digital input door
Relay 16Α res. 250VAC normally open contact / Max current load 16Α
Connections: cable cross section
Connections with terminal blocks 18A using cable with
Operating temperature: -15÷+55°C / Storage temperature: -20÷+80°C
Dimensions 37x79x81mm / The device is mounted on a panel hole 29x71mm and it is restrained with plastic side brackets / Protection IP65 front

SERIAL INPUT

VD1F can connect to a memory key or to data logger model Mini Logger or to CAMIN network:
 Memory key: parameter's values can be downloaded to the memory key or can be uploaded to the thermostat from the memory key.
 Mini Logger: the thermostat can connect to a data logger and store temperatures, relay status and alarms to a microSD. A cable is used to connect the data logger with the
thermostat and parameter Add must be adjusted to 1.
 CAMIN network: the thermostat can connect via a network interface NET-INS-485 to the CAMIN network. CAMIN is a software application designed to collect data, monitor
and fully control a network of up to 250 thermostats using cable wiring. It can also send SMS and emails in case of an alarm.
3 indication digits with resolution 0.5°C and 4 buttons; one serial input for controlling the cabinet's door; one relay 16Α 250VAC; automatic
Display indications
or change its value.
and the parameter Cod is displayed.
to enter the value 31. Press
.
parameter Cod must be adjusted to 22 (see parameter table next page).
th
2.5 mm² for all relays / cable cross section
cable cross section
relay ON in cooling mode
relay ON in heating mode
defrost ON
alarm ΟΝ
malfunction ON
to store the value to parameter Cod.
for more than 3 seconds.
or and press to display its value.
to store the new value.
from 0.25 to 1.0 mm² for the sensors and door switch
up to 2.5 mm² / It is recommended using a torque wrench with maximum torque 0.4Nm
can connect to the monitoring and controlling
Keyboard
enter/exit the parameter's menu
display the parameter's value
enter parameter's value
manual defrost or manual heating with
countdown
up arrow
OFF device (check below)
down arrow
mute buzzer
ON/OFF device (check below)
o C with temperature range -50÷+110°C (-58÷+230°F)
Firmware V2
