KIOUR RSD Quick Start Manual

TEMPERATURE CONTROLLER TOUCH LINE Model RSD

DESCRIPTION

RSD is a temperature controller for refrigerator rooms using touch technology for the keyboard. Through a
58÷+302°F). In scale -19.9÷+99.9°C there is a decimal analysis with accuracy ±0.1°C.
buzzer activation due to an alarm. The controller has a serial input and can connect to the KIOUR CAMIN modbus network for full monitoring and data logging of the device.

INDICATIONS AND BUTTON OPERATIONS

Indications
compressor ON
fan ON
defrost ON
heater ON
locked keyboard
sensor malfunction
STARTING UP - SWITCHING ON/OFF THE DEVICE
At the startup of the device, the temperature controller performs a self-check for 7sec and the room's temperature is displayed. Do not touch the screen during self-check. By
pressing the two buttons ([ ], [
we turn ON or turn OFF the controller (images

PROGRAMMING THE PARAMETERS

By pressing [ ] we enter the parameter's menu.
The first parameter "SPO" is displayed and with [
By pressing [SET] the value of the parameter is displayed and with the [
By pressing [ ] we confirm the new value and the name of the parameter is displayed.
By pressing [SET] we cancel the new value and the name of the parameter is displayed.
By pressing [ ] we exit the parameters menu.

TECHNICAL SPECIFICATIONS

Power supply: 230VAC 50/60Hz / Maximum power consumption: 3W
It is recommended to use a power supply safety switch: fuse 0,5A (not included)
Cabinet's temperature sensor PTC 1Κ 25
Relay compressor 250VAC 30A resistive load 2HP / Relays fan, water level 250VAC 10A
Operating temperature: -15÷+70°C / Storage temperature: -20÷+80°C
The device is mounted through panel hole 29x71mm and secured with snap-in brackets

CONNECTIONS - DIMENSIONS

SERIAL INPUT
RSD can connect to the key programmer or to the data logger Mini Logger or to the KIOUR CAMIN network or to any modbus network.
 Key programmer: controller's parameter values can be saved or retrieved from the programming key. Plug in the programming key to the controller and press at the same
time [SET]+[ ]. The device connects to the key and the message "Eo" is displayed. By pressing [
"ro" = read O.K. or "rF" = read Fail is displayed. By pressing [
displayed. In case of failure (rF or YF) reenter the key to the serial input and repeat the procedure from the beginning. The key can connect to all KIOUR devices. If you try
to read the parameters of a different device, message "rF" is displayed. At any time, we can perform the aforesaid operation. After 10sec the key is disconnected.
 Data logger Mini Logger: the controller is connected to the data logger via cable and by programming the parameter Add = 1. Automatically, based on selected minutes,
the data logger writes to a microSD memory card the controller's temperatures, status and alarms.
 CAMIN network: the controller can connect to the CAMIN network via an interface NET-INS-485. CAMIN is an PC software application designed to collect information,
watch and fully control a net of KIOUR devices while sending SMS and email in case of an alarm. The maximum length of the net can be 1000 meters.
button
enter parameter's menu
temperature scale indication °C/°F
MUTE
T2
df
] at the same time for 3 seconds the countdown starts and
below). The keyboard locks automatically after 50sec without activity.
], [ ] we scroll into the parameters with the order they appear to parameters table below
o C / Accuracy: 0.5°C
] the device uploads the parameters to the key and the message "Yo" = Write O.K. or "YF" = Write Fail is
It has three relays (compressor, fan, level control).
pressed once
confirm new value
mute buzzer
-
cancel new value
the temperature controller unlocks
], [ ] we change the value.
] the device downloads the parameters from the key and the message
PTC sensor controls room's temperatures in range -50÷+150°C
Operations
pressed more than 3 sec
pressed at the same time
-
ON/OFF controller
-
manual defrost
(images
By pressing more than 3sec the
button [ ] we switch ON or OFF
(-
It has also defrost control and a
-
unlock device
-
below). By pressing [ ] for 3sec
.
